GMB-C2165-LLVA
Industrial Motherboard
ATX Board
User's Manual
Version 1.0
Copyright © CONTEC, Inc., 2013 All rights reserved.
All other brand names are registered trademarks of their respective owners.
GMB-C2165-LLVA User‟s Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMB-C2165-LLVA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Contec GMB-C2165-LLVA

Summary of Contents for Contec GMB-C2165-LLVA

  • Page 1 GMB-C2165-LLVA Industrial Motherboard ATX Board User's Manual Version 1.0 Copyright © CONTEC, Inc., 2013 All rights reserved. All other brand names are registered trademarks of their respective owners. GMB-C2165-LLVA User‟s Manual...

  • Page 2: Table Of Contents

    Intel® Active Management Technology (Intel® AMT) Clear CMOS Operation WDT Function GPIO BIOS Setup Information Entering Setup -- Launch System Setup Main Configuration Security Boot Exit Troubleshooting Hardware Quick Installation BIOS Setting System Memory Address Map Appendix A Appendix GMB-C2165-LLVA User‟s Manual...

  • Page 3: How To Use This Manual

    Preface How to Use This Manual The manual describes how to configure your GMB-C2165-LLVA system board to meet various operating requirements. It is divided into five chapters, with each chapter addressing a basic concept and operation of Single Host Board.

  • Page 4: System Overview

    Core i3/Xeon processors, VGA, DVI-D, Display port, USB 3.0 and SATA III support which USB 3.0 is first integrated. GMB-C2165-LLVA based on the latest 3nd Gen Intel® Xeon Processor which offers 22nm Hi-K process technology with energy efficient architecture. GMB-C2165-LLVA adopts four channels DDR3 long DIMMs up to 32GB.
  • Page 5 ● Main Memory -Four 240-pin DDR3 DIMM (ECC/non-ECC) socket support up to 32GB dual channel 1600/1333MHz memory -GMB-C2165-LLVA supports Non-ECC memory ● Expansion Interface One PCIe x16 slot One PCIe x16 slot (setting jump to support two PCIe x8 from CPU)
  • Page 6 4.76~5.02V / 530mA ● Configuration: CPU Type Intel(R) Xeon(R) CPU E3-1275 V2 @ 3.50GHz L3 8MBytes SBC BIOS CONTEC, Inc. GMB-C2165-LLVA Rev.:R1.00.W1 (06102013) Memory WARIS DDR3 ECC-DIMM 1600/8GB (hynix H5TQ4G83MFR) x 4 VGA Card ONBOARD Intel(R) HD Graphics P4000 VGA Driver Intel(R) HD Graphics P4000 Version:9.17.10.2753...
  • Page 7 SEAGATE ST39173W SATA HDD Seagate ST250DM000 250GB CDROM ASUS DRW-24D3ST DVD-ROM Power Supply CONTEC ORION-D4601 ● ● Operating Temperature 0 °C ~ 60 °C ● Storage temperature -20 ~ 80 °C ● Relative Humidity 0% ~ 90%, non-condensing GMB-C2165-LLVA User‟s Manual...

  • Page 8: Mechanicaldrawing

    System Overview 1.3.1 MechanicalDrawing GMB-C2165-LLVA User‟s Manual...
  • Page 9 System Overview GMB-C2165-LLVA User‟s Manual...

  • Page 10: System Architecture

    System Overview 1.4. System Architecture All of details operating relations are shown in GMB-C2165-LLVA System Block Diagram. GMB-C2165-LLVA System Block Diagram GMB-C2165-LLVA User‟s Manual...

  • Page 11: Hardware Configuration

    Hardware Configuration This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the configuration jumpers on GMB-C2165-LLVA are in the proper position. The default settings shipped from factory are marked with an asterisk (★).
  • Page 12 JP3: Control CFG to Select PCIE x16 or x8 PIN No. Signal Description 1-2 short select x8 1-2 open select x16 JP4: Control Switch to Select PCIE x16 or x8 PIN No. Signal Description 1-2 short select x8 1-2 open select x16 GMB-C2165-LLVA User‟s Manual...
  • Page 13 Signal Description PIN No. Signal Description PWR_LED(+) Speaker(+) PWR_LED(-) J4 LAN1_ACT(+) J4 LAN1_LINK(-) Speaker(-) J5 LAN2_LINK(-) Power Button J5 LAN2_ACT(+) HDD_LED(+) HDD_LED(-) Rest J8: ATX 4Pin 12V Power Connector PIN No. Signal Description Ground Ground +12V +12V GMB-C2165-LLVA User‟s Manual...
  • Page 14 SMBus_CLK Ground SMBus_DAT J15: Case Open Connector PIN No. Signal Description Case open J16: External Keyboard/Mouse Connector Signal Description PIN No. Signal Description Mouse Data Keyboard Data Ground Ground PS2 Power PS2 Power Mouse Clock Keyboard Clock GMB-C2165-LLVA User‟s Manual...
  • Page 15 J20: CPU FAN Power Connector PIN No. Signal Description Ground +12V Fan on/off output Fan Speed control J23/24: COM3/COM4 Serial Port Connector Signal Description Signal Description DCD (Data Carrier Detect) DSR (Data Set Ready) RXD (Receive Data) RTS (Request to Send) GMB-C2165-LLVA User‟s Manual...
  • Page 16 TXD (Transmit Data) CTS (Clear to Send) DTR (Data Terminal Ready) RI (Ring Indicator) GND (Ground) J21/J26/J31: External USB Connector Signal Description PIN No. Signal Description 5V Dual 5V Dual USB- USB- USB+ USB+ Ground Ground 5V Dual GMB-C2165-LLVA User‟s Manual...

  • Page 17: Connector Allocation

    Lan Connector (LAN2) 82583V PCI-E x4 Slot Support x4 signal Front Panel System Connector ATX 4Pin 12V Power Connector SMBUS HEADER J10、J11、J12、J13 PCI Slot PCI-E x16 Slot Support PCI-E Gen3 Case Open Connector External Keyboard/ Mouse Connector GMB-C2165-LLVA User‟s Manual...
  • Page 18 SATA Connector(3Gb/s) J32、J35 SATA Connector(6Gb/s) ATX Power CFEX Slot System FAN Power Connector HDMI Port Clear CMOS ATX / AT Mode Select Control CFG to Select PCIE x16 or x8 Control Switch to Select PCIE x16 or x8 GMB-C2165-LLVA User‟s Manual...

  • Page 19: System Installation

    Alignment key LGA-1155 CPU In the top, the Yellow Triangle of the CPU is Pin1. Notch Please remember to locate the alignment keys on the CPU socket of the motherboard and the notches on the CPU. GMB-C2165-LLVA User‟s Manual...
  • Page 20 BIOS Setup Information LGA-1155 CPU Installation Steps Before install the CPU, please make sure to turn off the power first!! 1. Open the load lever. 2. Lift the load lever up to fully open GMB-C2165-LLVA User‟s Manual...
  • Page 21 3. Remove the plastic cap on the CPU socket. Before you install the CPU, always cover it to protect the socket pin. 4. After confirming the CPU direction for correct mating, put down the CPU in the socket housing frame. Note that alignment keys are matched. GMB-C2165-LLVA User‟s Manual...
  • Page 22 BIOS Setup Information 5. Make sure the CPU has been seated well into the socket. If not, take out the CPU and reinstall. 6. Engage the load lever while pressing down lightly onto the load plate. GMB-C2165-LLVA User‟s Manual...

  • Page 23: Main Memory

    Before locking, make sure that all modules have been fully inserted into the card slots Note: To insure the system stability, please do not change any of DRAM parameters in BIOS setup to modify system the performance without acquired technical information. GMB-C2165-LLVA User‟s Manual...

  • Page 24: Installing The Single Board Computer

    Step 1 : Check all jumpers setting on proper position. Step 2 : Install and configure CPU and memory module at right position. Step 3 : Place GMB-C2165-LLVA into the dedicated position in the system. Step 4 : Attach cables to existing peripheral devices and secure it.

  • Page 25: Intel® Proset Gigabit Ethernet Controller

    BIOS Setup Information 3.3.3 Intel® PROSet Gigabit Ethernet Controller Drivers Support Please find Intel® 82583V and 82579LM LAN driver form GMB-C2165-LLVA CD- title. 3.3.4 Audio Controller Please find Realtek ALC886-GR (Intel® High Definition Audio driver) form GMB- C2165-LLVA CD-title. 3.3.5 Intel®...
  • Page 26 2) 0x2F:EFDR (Extended Function Data Register, for accessing desired CR) WDT Control Command Example #include <stdio.h> #include <conio.h> #include <dos.h> #define SIO_Port 0x2E #define SIO_Port2 0x4E #define GPIO_LDN 0x07 void Enter_IT8783_SIO() { outportb(SIO_Port, 0x87); outportb(SIO_Port, 0x01); outportb(SIO_Port, 0x55); outportb(SIO_Port, 0x55); GMB-C2165-LLVA User‟s Manual...

  • Page 27: Gpio

    I/O function. GPIO Pin Assignment The GMB-C2165-LLVA provides 4 input/output ports that can be individually configured to perform a simple basic I/O function. Users can configure each individual port to become an input or output port by programming register bit of I/O Selection.
  • Page 28 J17: General Purpose I/O Connector Signal Description PIN No. Signal Description LPC_GP60 LPC_GP64 LPC_GP61 LPC_GP65 LPC_GP62 LPC_GP66 LPC_GP63 LPC_GP67 Note: All General Purpose I/O ports can only apply to standard TTL±5% signal level (0V/5V), and each Fan. GMB-C2165-LLVA User‟s Manual...
  • Page 29 #include <string.h> #include <dos.h> //Common defines #define HIGH 1 #define LOW 0 #define IN 1 #define OUT 0 //Prototype defines Int Get_IT8783_GPIOBase( int IOINDEX void Enter_IT8783_SIO( int IOINDEX void Exit_IT8783_SIO( int IOINDEX void Set_IT8783_LDN( int IOINDEX, int LDN GMB-C2165-LLVA User‟s Manual...
  • Page 30 GPIOBASE = GPIOBASE + Get_IT8783_Byte_Val(IOINDEX,0x63); return GPIOBASE; /******************************************************* Procedure Name : Enter IT8783 Super IO Check defines in config file name input 1 : INT IOINDEX *******************************************************/ void Enter_IT8783_SIO(int IOINDEX){ int IODATA = IOINDEX + 1; outportb(IOINDEX,0x87); outportb(IOINDEX,0x01); outportb(IOINDEX,0x55); GMB-C2165-LLVA User‟s Manual...
  • Page 31 Input 2: INT offset return: INT Data (Byte) *******************************************************/ int Get_IT8783_Byte_Val( int IOINDEX, int offset ){ int Data; int IODATA = IOINDEX + 1; outportb(IOINDEX,offset); //set offset of data read Data = inportb(IODATA); //Get Data from offset return Data; GMB-C2165-LLVA User‟s Manual...
  • Page 32 Data ) { //GPIO Mode is Output if(GPIOMode = 0){ Set_IT8783_Byte_Val(0x2E,0xCD,Get_IT8783_Byte_Val(0x2E,0xCD)| (1<<0)); //if Data is HIGH if(Data==1){ outportb(0x0A00 + 5, 1<<0); //if Data is LOW if(Data==0){ outportb(0x0A00 + 5, (inportb(0x0A00 + 5) & ~(1<<0) ) ); return NULL; GMB-C2165-LLVA User‟s Manual...
  • Page 33 //if Data is LOW if(Data==0){ outportb(0x0A00 + 5, (inportb(0x0A00 + 5) & ~(1<<1) ) ); return NULL; //GPIO Mode is Input else if(GPIOMode = 1){ Set_IT8783_Byte_Val(0x2E,0xCD,Get_IT8783_Byte_Val(0x2E,0xCD) & ~(1<<1)); Data = inportb(0x0A00 + 5) & (1<<1); return Data; GMB-C2165-LLVA User‟s Manual...
  • Page 34 + 5, (inportb(0x0A00 + 5) & ~(1<<2) ) ); return NULL; //GPIO Mode is Input else if(GPIOMode = 1){ Set_IT8783_Byte_Val(0x2E,0xCD, Get_IT8783_Byte_Val(0x2E,0xCD) & ~(1<<2)); Data = inportb(0x0A00 + 5) & (1<<2); return Data; return NULL; /******************************************************* GMB-C2165-LLVA User‟s Manual...
  • Page 35 Procedure Name: Set GPIO Pin 5 Mode & In/Out data Description: Set GPIO Pin I/O Mode if GPIOMode is Input , input 2 data will don‟t care. and this function will return read value. Pin 5: GP64 Input 1: INT GPIOMode GMB-C2165-LLVA User‟s Manual...
  • Page 36 Pin 6: GP65 Input 1: INT GPIOMode Input 2: INT Data Out 1: INT Data *******************************************************/ int SET_GPIO_PIN6( int GPIOMode, int Data ) { //GPIO Mode is Output GMB-C2165-LLVA User‟s Manual...
  • Page 37 Input 2: INT Data Out 1: INT Data *******************************************************/ int SET_GPIO_PIN7( int GPIOMode, int Data ) { //GPIO Mode is Output if(GPIOMode = 0){ Set_IT8783_Byte_Val(0x2E,0xCD, Get_IT8783_Byte_Val(0x2E,0xCD) (1<<6)); //if Data is HIGH if(Data==1){ outportb(0x0A00 + 5, 1<<6 ); GMB-C2165-LLVA User‟s Manual...
  • Page 38 = 0){ Set_IT8783_Byte_Val(0x2E,0xCD, Get_IT8783_Byte_Val(0x2E,0xCD) (1<<7)); //if Data is HIGH if(Data==1){ outportb(0x0A00 + 5, 1<<7 ); //if Data is LOW if(Data==0){ outportb(0x0A00 + 5, (inportb(0x0A00 + 5) & ~(1<<7) ) ); return NULL; //GPIO Mode is Input GMB-C2165-LLVA User‟s Manual...
  • Page 39 BIOS Setup Information else if(GPIOMode = 1){ Set_IT8783_Byte_Val(0x2E,0xCD, Get_IT8783_Byte_Val(0x2E,0xCD) & ~(1<<7)); Data = inportb(0x0A00 + 5) & (1<<7); return Data; return NULL; GMB-C2165-LLVA User‟s Manual...

  • Page 40: Bios Setup Information

    BIOS Setup Information BIOS Setup Information GMB-C2165-LLVA is equipped with the Phoenix BIOS stored in Flash ROM. These BIOS has a built-in Setup program that allows users to modify the basic system configuration easily. This type of information is stored in CMOS RAM so that it is retained during power-off periods.

  • Page 41: Main

    Use this menu for basic system configurations, such as time, date etc. System Date The date format is <Month>, <Day> and <Year>. Use [＋] or [－] to configure system Date. System Time The time format is <Hour>, <Minute> and <Second>. Use [＋] or [－] to configure system Time. GMB-C2165-LLVA User‟s Manual...

  • Page 42: Configuration

    BIOS Setup Information Configuration Use this menu to set up the items of special enhanced features Boot Configuration Set boot configuration. GMB-C2165-LLVA User‟s Manual...
  • Page 43 Diagnostic Summary Screen Display the Diagnostic summary screen during boot. Choices: Disabled, Enabled. Allow Hotkey in S4 resume Enable hotkey detection when system resuming from Hibernate state. Choices: Disabled, Enabled. UEFI Boot Enable the UEFI boot. Choices: Disabled, Enabled. GMB-C2165-LLVA User‟s Manual...
  • Page 44 BIOS Setup Information PCI/PCIE Configuration Configure PCI/PCI Express slot. Processor PCI Express Configuration GMB-C2165-LLVA User‟s Manual...
  • Page 45 Configure PFG3 B0:D0:F3 Speed. Choices: Auto, Gen1, Gen2, Gen3 ICH PCI Express Configuration DMI Link ASPM Control The control of active state Power Management on both NB side of the DMI Link. Choices: Disabled, L0s, L1, L0sL1 and Auto. GMB-C2165-LLVA User‟s Manual...
  • Page 46 Choices: Auto, Gen1, Gen2. ASPM Control PCIe Active State Power Management settings. Choices: Disabled, L0S, L1, L0S and L1, Auto. HOT PLUG PCI Express Hot Plug Enabled/Disabled. Choices: Disabled, Enabled. PCI Express Unsupported Request Reporting Enable/Disable. Choices: Disabled, Enabled. GMB-C2165-LLVA User‟s Manual...
  • Page 47 Root PCI Express System Error on Non-Fatal Error Enable/Disable. Choices: Disabled, Enabled. SECE Root PCI Express System Error on Correctable Error Enable/Disable. Choices: Disabled, Enabled. PME Interrupt Root PCI Express PME Interrupt Enable/Disable. Choices: Disabled, Enabled. PME SCI PCI Express PME SCI Choices: Disabled, Enabled. GMB-C2165-LLVA User‟s Manual...
  • Page 48 Choices: Disabled, Enabled Wake system with Fixed Time Enable or disable system wake on alarm event. When Enabled, system will wake on the hr: min: sec specified. Choices: Disabled, Enabled Wake up By PS/2 Keyboard Choices: Enabled, Disabled. GMB-C2165-LLVA User‟s Manual...
  • Page 49 Configure the specific active core(s) and advanced processor management technologies. Hyper-Threading Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology). When disabled only one. Choices: Disabled, Enabled. GMB-C2165-LLVA User‟s Manual...
  • Page 50 Selects Disabled or Enabled for CPU operating states. Choices: Disabled, Enabled. VT-x When enabled, a VWM can utilize the additional hardware capabilities provided by Vander pool Technology. Choices: Disabled, Enabled. Local x2APIC Selects Disabled or Enabled for Advanced Programmable Interrupt Controller. Choices: Disabled, Enabled. GMB-C2165-LLVA User‟s Manual...
  • Page 51 Enabled/Disabled Wake on LAN Function. Choices: Disabled, Enabled. LAN Boot ROM Control LAN Boot ROM (PXE) function. Choices: Disabled, Enabled. Intel 82583V LAN Enabled/Disabled 82583V LAN. Choices: Disabled, Enabled. Wake on LAN Enabled/Disabled Wake on LAN Function. Choices: Disabled, Enabled. GMB-C2165-LLVA User‟s Manual...
  • Page 52 BIOS Setup Information Chipset Configuration Configure Chipset provide feature. VT-d Check to enable VT-d function on MCH. Choices: Disabled, Enabled. GMB-C2165-LLVA User‟s Manual...
  • Page 53 PEG ASPM Control ASPM (Active State Power Management) Support for the PEG Device. This has mp effect if PEF is not the current active service. Choices: Disabled, Auto, ASPM L0s, ASPM L1, ASPM L0sL1. Choices: Enabled, Disabled. GMB-C2165-LLVA User‟s Manual...
  • Page 54 Choices: Dynamic, 1GB, 1.25GB, 1.5GB, 1.75GB, 2GB, 2.25GB, 2.5GB, 2.75GB, 3GB, 3.25GB, 3.5GB. Memory Frequency Maximum Memory Frequency Selections in Mhz. Choices: Auto, 1067, 1333, 1600, 1867, 2133. Memory ECC Support Selects ECC memory function Disable/Enable. Choices: Disable, Enable. GMB-C2165-LLVA User‟s Manual...
  • Page 55 Control detection of the Azalia device. Choices: Disable, Enable. Azalia PME Enable Choices: Disable, Enable. Azalia Vci Enable Choices: Disable, Enable. Azalia Internal HDMI codec Choices: Disable, Enable. HDMI codec Port B Choices: Disable, Enable. HDMI codec Port C Choices: Disable, Enable. GMB-C2165-LLVA User‟s Manual...
  • Page 56 Select which of IGFX/PEG/PCI Graphics device should be Primary Display or select SG for Switchable Gfx. Choices: Auto, IGFX, PEG and PCI. Internal Graphics Keep IGD Enabled Based on the setup options, Choices: Auto, Disabled, Enabled. Aperture Size Select the Aperture Size Choices: 128MB, 256MB, 512MB. GMB-C2165-LLVA User‟s Manual...
  • Page 57 Select DVMT 5.0 Total Graphics Memory size used by the Internal Graphics Device. Choices: 128MB, 256MB, MAX. Primay Boot display Choices: VBIOS Default, CRT, LFP, LFP2, EFP, EFP2, EFP3. SATA Configuration Configure SATA controller and view detected HDD Information. GMB-C2165-LLVA User‟s Manual...
  • Page 58 Choices: Hard Disk Driver, Solid State Drive. CFex Choices: Empty. CFex Enabled or Disabled CFex Port. Choices: Disabled, Enabled. Hot Plug Designates this port as Hot Pluggable. Choices: Disabled, Enabled. External Port External SATA Support. Choices: Disabled, Enabled. GMB-C2165-LLVA User‟s Manual...
  • Page 59 Configure USB controller and other advanced setting. Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Choices: Enabled, Disabled. GMB-C2165-LLVA User‟s Manual...
  • Page 60 BIOS Setup Information PCH USB Configuration Control each of the USB ports disabling. USB Ports Per-Port Disable Control each of the USB ports disabling. Choices: Enabled, Disabled. GMB-C2165-LLVA User‟s Manual...
  • Page 61 BIOS Setup Information ME Configuration Configure Management Engine Technology Parameters. Intel (R) ME Enable/Disable Intel (R) Management Engine. Choices: Enabled, Disabled. GMB-C2165-LLVA User‟s Manual...
  • Page 62 Choices: Disabled, 3F8/IRQ4, 2F8/IRQ3, 3E8/IRQ5, 2E8/IRQ6, 220/IRQ7, 228/IRQ11. COM2 Configuration Select Com2 Configuration. Choices: RS-232, RS-422, RS-485. Watch Dog Timer Select Choices: Disabled, 30 secs, 1 min, 2 mins and 3 mins. Case Open Warning Choices: Disabled, Enable. GMB-C2165-LLVA User‟s Manual...

  • Page 63: Hardware Monitor

    BIOS Setup Information Hardware Monitor Provide on board sensor reading information. (Show only) CPU Fan Feature GMB-C2165-LLVA User‟s Manual...
  • Page 64 BIOS Setup Information Smart Fan Control Choices: Enabled, Disabled. Serial Port Console Configuration Configure console redirection on serial port. Console Redirection Control Console Redirection enable/disable. Choices: Enabled, Disabled. GMB-C2165-LLVA User‟s Manual...

  • Page 65: Security

    Press Enter to type Supervisor Hint String. Set User Password Set or clear the User account‟ password. Supervisor Hint String Press Enter to type User Hint String. Min. password length Set the minimum number of characters for password (1-20). GMB-C2165-LLVA User‟s Manual...

  • Page 66: Boot

    Use this menu to specify the priority of boot devices. Boot Priority Order Keys used to view or configure devices:↑and↓arrows Select a device. „+‟ and „-„move the device up or down. „Shift + 1‟ enabled or disables a device. „Del‟ deletes an unprotected device. GMB-C2165-LLVA User‟s Manual...

  • Page 67: Exit

    Load Setup Defaults Equal to F9. Load standard default values. Discard Changes Load the original value of this boot time. Not the default Setup value. Save Changes Save all changes of all menus, but do not reset sys GMB-C2165-LLVA User‟s Manual...

  • Page 68: Troubleshooting

    Troubleshooting Troubleshooting This chapter provides a few useful tips to quickly get GMB-C2165-LLVA running with success. As basic hardware installation has been addressed in Chapter 2, this chapter will focus on system integration issues, in terms of BIOS setting, and OS diagnostics.

  • Page 69: Bios Setting

    SATA hard disk, DVI connector, but it only can use on DVI-D function, doesn‟t support DVI-I function, device power cables, ATX accessories are good examples that deserve attention. With no assurance of GMB-C2165-LLVA User‟s Manual...
  • Page 70 To make sure that you have a successful start with GMB-C2165-LLVA , it is recommended, when going with the boot-up sequence, to hit “DEL” key and enter the BIOS setup menu to tune up a stable BIOS configuration so that you can wake up your system far well.

  • Page 71: System Memory Address Map

    Memory Area Size Description 0000-003F Interrupt Area 0040-004F 0.3K BIOS Data Area 0050-006F 0.5K System Data 0070-0548 0549-0FC2 Program Area 0FC3-9B7F 558K 【Available】 9B80-9D7F Unused First Meg -- Conventional memory end at 630K -- 9D80-9DFF Extended BIOS Area GMB-C2165-LLVA User‟s Manual...
  • Page 72 Troubleshooting 9E00-9FFF Unused A000-AFFF VGA Graphics B000-BFFF Unused C000-CE5F VGA Text CE60-EFFF Video ROM 134K Unused GMB-C2165-LLVA User‟s Manual...
