Foscam FI9853EP Quick Installation Manual

Quick Installation Guide
（For Windows & Mac OS）
HD IP Camera
V4.5
EQ985305
2
1. Insert the CD into the CD drive of your computer.
2. Go to the folder "IP Camera Search Tool" and nd the folder "For
Windows OS"or "For Mac OS". Copy and paste the IP camera tool le
to your computer, or drag it onto your desktop.
Notes:
you can nd the corresponding le in the opened control panel.
the IP camera tool from our website for free.
ShenZhen Foscam Intelligent Technology Co., Ltd
www.foscam.com
1
Package Contents
IP Camera Power Adapter
Ethernet Cable Resource CD
Quick Installation Guide
（For Windows & Mac OS）
HD IP Camera
Warranty Card
Quick Installation Guide
1

Software Installation

Shortcut icon for Windows OS
Shortcut icon for Mac OS
If your computer ( Windows OS ) supports autorun function,
If your computer doesn't have CD drive, you can download
5

Hardware Introduction

Physical Description
Power
LAN
Reset Button
LENS
Array LED

Hardware Installation

1. Loosen the three screws on the base of the camera, remove
the camera base.
2
3

Access the Camera

1. Enable the DHCP feature of your router (Enabled by default
normally), then open the IP Camera Tool program. It should
display the camera's IP address in your LAN (Local Area Network).
2. Double click the camera list here, and your default browser will
open up to the camera's login page. When logging in for the rst
time, you will need to download and install the add-on. Take
Microsoft Internet Explorer as an example. For Google Chrome,
Apple Safari, or Mozilla Firefox, please refer to the User Manual.
Note： Note：
Doesn't support 64-bit browser.
Click Install
6
2. According to the monitored area, install the base of the
camera on the ceiling or wall with expansion screws.
Assembly the sphere, cover and decorative ring of the order,
3.
according to the monitored area to turn the angle of the
sphere. Finally, x the decorative ring and the base with screws.
Ceiling or wall
Base
Sphere
Cover
Decorative ring
3
3. After installing the add-on, refresh the browser and click Login.
Default user is admin with no
Default user is admin with no
password.
password.
Main stream o ers the highest Main stream o ers the highest
quality video while Sub stream quality video while Sub stream
o ers less quality, but also less o ers less quality, but also less
delay when viewing. delay when viewing.
4. When you login for the rst time, it will request that you
modify the default username and/or password. Input the New
username, New password, and Confirm the password click
,
Modify to complete the modi cation. You will now use the new
username and password to login to the camera in the future.
Input the New username, Input the New username,
New password and New password and
Con rm the password. Con rm the password.
7

Hardware Connection

WPS WPS
1. Connect the camera to the LAN network (Router or Switch)
via network cable.
2. Connect the power adapter to the camera.
4
5. After logging in, you should see live video on the interface.
Notes:
After logging in for the rst time, it will go to "Setup
Wizard" automatically. Please set the basic parameters, such
as camera name, camera time and so on.
If you forget your username or password, you can press
and hold the reset button on the bottom of the camera using
a pin for 5 seconds. This resets the camera to factory defaults.
8
