Foscam FI9853EP Quick Installation Manual

Quick Installation Guide

（For Windows & Mac OS）
HD IP Camera
V4.9
EQ985308
CE Certi cate Website:
http://www.foscam.com/company/ce-certi cate.html
ShenZhen Foscam Intelligent Technology Co., Ltd
www.foscam.com
Package Contents
IP Camera Power Adapter Ethernet Cable
Quick Installation Guide
（For Windows & Mac OS）
HD IP Camera
Quick Installation Guide Warranty Card Resource CD
Security Warning
Foscam cameras and NVRs require good security practices
to safeguard your privacy. You should regularly change
your camera or NVR password which is 8-10 numbers,
letters, symbols combination.
You should update your camera or NVR regularly. Make
sure your camera or NVR has the latest rmware installed
for your speci c model and better experience.
Hardware Connection
WPS WPS
1. Connect the camera to the LAN network (Router or Switch)
via network cable.
2. Connect the power adapter to the camera.
1
Hardware Introduction
Physical Description
LENS
Array LED
Hardware Installation
1. Loosen the three screws on the base of the camera, remove
the camera base.
1
2

Software Installation

1. Insert the CD into the CD drive of your computer.
2. Go to the folder "Equipment Search Tool" and nd the folder
"For Windows OS"or "For Mac OS". Copy and paste the Equipment
Search Tool le to your computer, or drag it onto your desktop.
Notes:
If your computer ( Windows OS ) supports autorun function,
you can nd the corresponding le in the opened control panel.
If your computer doesn't have CD drive, you can download
the Equipment Search Tool from our website for free.
4
According to the monitored area, install the base of the
2.
camera on the ceiling or wall with expansion screws.
Assembly the sphere, cover and decorative ring of the order,
3.
Power
according to the monitored area to turn the angle of the
sphere. Finally, x the decorative ring and the base with screws.
LAN
Reset Button
2
3

Access the Camera

1. Enable the DHCP feature of your router (Enabled by default
normally), then open the Equipment Search Tool program. It
should display the camera's IP address in your LAN (Local Area
Network).
2. Double click the camera list here, and your default browser
will open up to the camera's login page. When logging in for
the rst time, you will need to download and install the
add-on. Take Microsoft Internet Explorer as an example. For
Google Chrome, Apple Safari, or Mozilla Firefox, please refer to
the User Manual.
Note： Note：
Doesn't support 64-bit browser.
5
Ceiling or wall
Base
Sphere
Cover
Decorative ring
3
6
