AUTOMAZIONI A BRACCIO PER CANCELLI A BATTENTE
ARM AUTOMATIONS FOR SWINg gATES
AUTOMATIONS A BRAS POUR PORTAILS BATTANTS
ARM AUTOMATIONEN FUER FLUgELgITTERTIRE
AUTOMATIZACIONES A BRAZO PARA PORTONES CON BATIENTE
AUTOMATIZAÇÕES DE BRAÇO PARA PORTÕES DE BATENTE
Attenzione! Leggere attentamente le "Avvertenze" all'interno! Caution! Read "Warnings" inside carefully! Attention! Veuillez lire attentivement les Avertissements qui se trouvent à l'intérieur!
Achtung! Bitte lesen Sie aufmerksam die „Hinweise" im Inneren! ¡Atención¡ Leer atentamente las "Advertencias" en el interior! Atenção! Ler atentamente as "Instruções " que se encontram no interior!
Advertisement
Related Manuals for BFT IGEA BT
Summary of Contents for BFT IGEA BT
- Page 1 027908 2 0 3 7 1 7 AUTOMAZIONI A BRACCIO PER CANCELLI A BATTENTE ARM AUTOMATIONS FOR SWINg gATES AUTOMATIONS A BRAS POUR PORTAILS BATTANTS ARM AUTOMATIONEN FUER FLUgELgITTERTIRE AUTOMATIZACIONES A BRAZO PARA PORTONES CON BATIENTE AUTOMATIZAÇÕES DE BRAÇO PARA PORTÕES DE BATENTE Attenzione! Leggere attentamente le “Avvertenze”...
- Page 2 Fig. A Fig. 1 Fig. 2 Fig. 3 93˚ 125˚ 90˚ 180˚ 180˚ 125˚ Fig. 4 Fig. 5 Sinistra / Left Destra / Right Gauche / Linke Droite / Rechts Izquierdo / Esquerda Derecha / Direita Fig. 6 Fig. 7 Fig.
- Page 3 Fig. 9 Fig. 9b Destra Sinistra Right Left Droite Gauche Rechts Linke Derecha Izquierdo Direita Esquerda Destra / Right / Droite Sinistra / Left / Gauche Sinistra / Left / Gauche Rechts / Derecha / Direita Linke / Izquierdo / Esquerda Linke / Izquierdo / Esquerda Fig.
- Page 4 Fig. 11 Fig. 12 R - FC1 R - FC2 R - FC2 R - FC1 Fig. 13 Fig. 14 d.c. d.c. MOT - MOT - MOT + MOT - MOT + MOT + MOT - MOT + N.O. N.O. N.O.
- Page 5 Fig. 15 Sinistra / Left Destra / Right Gauche / Linke Droite / Rechts Izquierdo / Esquerda Derecha / Direita Fig. 16 ø 5 mm IgEA-BT -...
- Page 6 THE DECLARATION OF CONFORMITY CAN bE vIEWED ON THIS WEbSITE: WWW.bFT.IT IN THE PRODUCT SECTION. - Only use original spare parts for any maintenance or repair work. The Firm dis- claims all responsibility for the correct operation and safety of the automated system if parts from other manufacturers are used.
- Page 7 INSTALLATION MANUAL 2) GENERAL OUTLINE draw an imaginary horizontal line from the centre of the reinforcement point This Low-voltage controller (24V) is suitable for residential use and has been to the gate post (fig.2). Position the anchoring bracket according to the values given in fig.
-
Page 8: Maintenance
INSTALLATION MANUAL relevant standards in force. CAUTION! Excessive torque adjustment may jeopardise the anti-squash safety function. On the other hand insufficient torque adjustment may not guarantee correct opening or closing strokes. 10) EMERGENCY MANOEUVRE (Fig. 15) In the case of power failure or operation malfunctions, manual emergency manoeuvre can be carried out by turning the external release knob with per- sonalised key. - Page 9 MANUALE D’USO: MANOVRA DI EMERGENZA / USER GUIDE:EMERGENCY OPERATION- MANUEL D’UTILISATION: DE LA MANŒUVRE D’URGENCE / BEDIENUNGSHANDBUCH: NOTFALLMANÖVER- MANUAL DE USO: MANIOBRA DE EMERGENCIA / MANUAL DE USO-MANOBRA DE EMERGÊNCIA Fig. 1 Destra / Right Sinistra / Left Droite / Rechts Gauche / Linke Derecha / Direita Izquierdo / Esquerda...
-
Page 10: Sicurezza Generale
qualificato ed esperto (installatore professionale) AVVERTENZE PER L’UTILIZZATORE ( I ) secondo quanto indicato dall’installatore o dal costruttore della porta. ATTENZIONE! Importanti istruzioni di sicurezza. - Per ogni operazione di pulizia esterna, togliere Leggere e seguire attentamente le Avvertenze l’alimentazione di rete. e le Istruzioni che accompagnano il prodotto - Tenere pulite le ottiche delle fotocellule ed i dispo- poiché... -
Page 11: General Safety
