Hardware Differences

The FDM had no capability of supplying the target power whereas the E8Direct can supply 3.3V or 5V and
the FDM-E8Direct pin usage is different. This means that it is not possible to simply swap an FDM for an
E8. The general purpose I/O pins on the FDM were labelled as MD0 to MD4 and FWE, and they had a
direct mapping with the mode pins with matching names on the target devices. Because the number of
available general purpose I/O pins is reduced on the E8, and the locations on the 14-pin header are
different, we can no longer have a direct mapping between device mode pin names and E8 I/O pins, so we
have chosen to label them as 'A', 'B', 'C' and 'D'. The pin settings required for E8Direct will have to be
board specific rather than device specific.
FDM Pin Name
Pin
14-pin connector
No.
1
SCK
2
GND
3
FWx
4
MD0
Txd (Input from Txd of
5
Target device to Rxd of
2148AF on FDM)
6
MD1
7
MD4
8
UVCC Input
9
PVCC Input
10
MD2
Rxd (Output to Rxd of
11
Target device from Txd0
of 2148AF on FDM)
12
MD3
13
RESET
14
UCONNECT
15
-
16
-
17
-
18
-
19
-
20
-
20-pin connector (Japan
only)
/
RES
GND
FWx
GND
MD0
GND
MD1
GND
MD2
GND
MD3
GND
MD4
GND
RXD (TXD for the user
system)
GND
TXD (RXD for the user
system)
VIN (Vcc or PVcc)
NC
VIN (PVcc)
E8 Direct Pin Name
Output D
GND
Output C
Output A
Target Txd (Input from Txd
of Target device to Rxd0 of
2215UF on E8)
GND (Connected to GND on E8)
Output B
UVCC (can supply 3.3 or 5V
or detect if target is
powered)
BUSY (Not used for E8Direct)
GND (Connected to GND on E8)
Target Rxd (Output to Rxd of
Target device from Txd0 of
2215UF on E8)
GND (Connected to GND on E8)
RESET
UCONNECT (Connect to GND on
Target board)
-
-
-
-
-
-
