1
Using the Phone....................................................................................................................................
1.1
Making Phone Calls....................................................................................................................
1.1.1 Make / Receive Second Call.......................................................................................................
1.1.2 Call Transfer................................................................................................................................
1.2
Using Phonebook........................................................................................................................
1.3
Voice Message............................................................................................................................
1.4
Do-Not-Disturb...........................................................................................................................
1.5
Call Forward................................................................................................................................
User Manual
X4
<文档标题>

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X4 and is the answer not in the manual?

Questions and answers

Related Manuals for Fanvil X4

Summary of Contents for Fanvil X4

  • Page 1 <文档标题> User Manual Using the Phone............................ Making Phone Calls........................1.1.1 Make / Receive Second Call....................... 1.1.2 Call Transfer..........................Using Phonebook........................Voice Message..........................Do-Not-Disturb........................... Call Forward..........................

  • Page 2: Using The Phone

    <文档标题> Keypad Figure 6 - Vertical Scroll Bar Using the Phone Making Phone Calls  Default Line The device provides 4 line services. If both lines are configured, user can make or receive phone calls on either line. If default line is configured by user, there will be a default line to be used for making outgoing call which is indicated on the top left corner.
  • Page 3 <文档标题> [Menu] - > [Features] -> [Default Line] or configure from Web Interface (Web / Phone settings / Features ). Figure 32 - Default Line  Dialing Methods User can dial a number by,  Entering the number directly  Selecting a phone number from phonebook contacts (Refer to 6.2 Using Phonebook) ...
  • Page 4 <文档标题> Figure 33 - Dialing a Number before Audio Channel Opened  Opening Audio then Dialing the Number Another alternative is the traditional way to firstly open the audio channel by lifting the handset, turning on the hands-free or headset by pressing hands-free button, or line key, and then dial the number with one of the above methods.
  • Page 5 <文档标题>  Cancel Call While calling the number, user can press [End] button or close the audio channel by put back the handset or press the hands-free button to drop the call. Figure 35 - Calling Remote Party  Answering Incoming Call When there is an incoming call while the device is idle, user will see the following incoming call alerting screen Figure 36 - Incoming Call Screen...
  • Page 6 <文档标题> To reject the incoming call, user should press [Reject] button. Talking When the call is connected, user will see a talking mode screen as the following figure,  Call Holding /Resuming User can hold the remote party by pressing [Hold] button and the button will be changed to [Resume] icon.
  • Page 7 <文档标题>  Second Incoming Call When there is another incoming call during talking a phone call, this call will be waiting for user to answer it. User will see the call message in the middle of current screen. The device will not be ringing but playing call waiting tone in the audio channel of the current call and the LED will be flashing in green.

  • Page 8: Call Transfer

    <文档标题> Figure 40 - Dual Calls User can press up/down navigation buttons to switch screen page, and switch call focus by pressing [Hold] / [Resume] button.  Ending One Call User may hang up the current talking call by closing the audio channel or press [End] button. The device will return to single call mode in holding state.
  • Page 9 <文档标题> This is like helping the first party to dial to the second one. However, the transfer could be successful if the second party answered it, or could be failed if the second party is busy or rejected it. NOTICE! More advanced transfer configuration, please refer to 8.14 LINES / Dial Plan. Using Phonebook User can save contacts’...

  • Page 10: Voice Message

    <文档标题> Figure 43 - Phonebook is Empty When there are contact records in the phonebook, the contact records will be arranged in the alphabet order. User may browse the contacts with up/down navigation keys. User may fast scroll the contact list by holding the up/down navigation keys.
  • Page 11 <文档标题> message notification from the server and device will prompt a voice message waiting icon on the standby screen, Figure 54 - New Voice Message Notification To retrieve the voice messages, user must configure the voice message number first. Once the voice message number is configured, user can retrieve the voice message of a line by pressing the [Dial] button in the voice message screen.
  • Page 12 <文档标题> Figure 55 - Voice Message Screen Figure 56 - Configure the Voice Message Number Do-Not-Disturb User may enable Do-Not-Disturb (DND) feature on the device to reject incoming calls (including call waiting). The DND can be enabled on line basis. To quickly enable or disable the DND on all lines, When the device is in the default standby mode, ...
  • Page 13 <文档标题>  Press [DND] button again to disable DND on all line and icon will be disappeared. Figure 57 - DND Enabled on All Lines If user wishes to enable or disable DND on a specific line, user could change the DND mode in DND configurations.

  • Page 14: Call Forward

    <文档标题> Call Forward Call forward is also known as ‘Call Divert’ which is to divert the incoming call to a specific number based on the conditions and configurations. User can configure the call forward settings of each line. There are three types, ...
  • Page 15 <文档标题> Figure 62 - Select Call Forward Type Figure 63 - Activate Call Forward and configure Call Forward Number...
  • Page 16 <文档标题> Table 11 - Keypad Icons Redial Handsfree (HF) Phone lock=long-pressed key(#) Mute microphone (during a Call) Volume up Volume down Table 12 - Status Prompt and Notification Icons Call out Call in Call hold Network disconnected Keypad locked Missed calls New voice message waiting Do-Not-Disturb activated on phone...
  • Page 17 <文档标题> Auto-answering activated Call forward activated Handsfree (HF) mode headset (HP) mode Handset (HS) mode Microphone muted Mixed type input Lower Case input Upper Case input Numeric input...
