- Page 1 Digit Collecting and Dialing Rule Description Version: <1.1> Release date: <2018-5-11>...
-
Page 2: Table Of Contents
Contents Contents ................................. 1 Introduction ............................2 Overview ............................ 2 Applicable Models ........................2 Operation Description ........................3 Basic Settings ..........................3 Customized Digit Collecting Rules .................... 9 2.2.1 Parameter Description ......................10... -
Page 3: Introduction
Introduction 1.1 Overview For Fanvil C series phones, most digit delivery and replacement requirements can be met by configuring dial plan and dial peer. However, for novices or users who have not use the two functions for a long time, it is difficult to configure the functions on the webpage without reading the instruction. -
Page 4: Operation Description
Operation Description 2.1 Basic Settings X34 supports eight dialing methods: Press # to invoke dialing: A # symbol is suffixed to the dialed number. Dial fixed length: The call is automatically dialed out when the entered number reaches the specified length. - Page 5 Press # to do blind transfer: After entering the transferred-to number, press # to transfer the call to the third party. Blind transfer on onhook: If you hang up or finish the call by pressing the handfree key after entering a number, the call is transferred to the third party.
- Page 6 Configure the timeout interval, in seconds. For example, when the timeout is set to 10 seconds, if you do not enter the second digit 10 seconds after the first digit, the phone considers that you have completed dialing and delivers the entered digit. Press # to do blind transfer Select Press # to Do Blind Transfer, enter the number on the transfer dialing interface, and press # to perform blind transfer.
- Page 7 Select Attended Transfer on Onhook, enter the number on the transfer dialing interface, and initiate a call. When the call is answered, hang up. The call is transferred. Attended transfer on conference onhook When the test phone has set up a call with phone B and phone C, press the handfree key in the handfree mode, press the headset key in the headset mode, or hang up in handle mode.
- Page 8 For the numbers starting with 0812/0813/0816/0817, 0825/0826/0827, 083, 085, 087, 0883/0886/0887/0888, and 089, the phone dials 11 digits (the numbers starting with 0850 and 0890/0899 are invalid). For the numbers starting with 0898, the phone dials 12 digits. 7. Start with 03, 04, 05, 06, 07, and 09 7.1.
- Page 9 7.4. Start with 06 (1) 0631/0632/0633/0634/0635: The phone dials 11 digits. (2) 0660/0662/0663/0668: The phone dials 11 digits. (3) 0691/0692: The phone dials 11 digits. 7.5. Start with 07 (1) 0701/071/0722/0724/0728: The phone dials 11 digits. (2) 073: The phone dials 11 digits, except for the numbers starting with 0731/0732/0733. The numbers starting with 0732 and 0733 are invalid.
-
Page 10: Customized Digit Collecting Rules
After adding a number to the memory key and pressing the transfer key, you can press this key to transfer the call to the third party. 2.2 Customized Digit Collecting Rules You can customize the dialing rules meeting your requirements and matching your server. The customized rules improve phone convenience and practicability. -
Page 11: Parameter Description
Parameter Description This is an optional parameter. For example, if the value is set to 3, the first 3 digits of the number are deleted. Note: There are four types of Note: aliases. The alias must be X indicates to match any digit. configured together with [ ] indicates the range of specified digits. - Page 12 You can delete or modify the added dialing rules. Add Dial Peer: Number: Configure a number. Destination (Optional): Configure the destination. Port (Optional): Configure the port. Suffix (Optional): Configure the suffix. Deleted Length (Optional): Set the length. Dial Peer Menu: The added dial peer can be deleted and modified.
- Page 13 Example 2: Partial replacement When you call a number in Beijing, you need to prefix the area code 010 to the number. After this function is configured, the number starting with 1 will be replaced with 010. For example, when you call a Beijing phone number 62213123, you only need to enter 162213123.
- Page 14 Example 5: Deleting prefix If a dialed number matches the prefix, the phone automatically deletes the prefix. For example, when the prefix is set to 9, if you enter 98322, the phone delivers 8322. The digit 9 is deleted. X56 and video phone: [1-8]xxx indicates that the 4-digit numbers ranging from 1000 to 8999 Example 1: are delivered immediately when the 4 digits are collected.
- Page 15 911 indicates the number. It is delivered immediately when the three Example 3: digits are entered. 99T4 indicates that the number 99 is delivered 4 seconds after being Example 4: entered. 9911x.T4 indicates a number of at least 5 digits starting with 9911. The Example 5: number will be delivered 4 seconds after being entered.
- Page 16 Note 2: Each number can match only one customized dialing rule. If a number matches multiple rules, no rule will take effect. See the figure below:...
