Summary of Contents for Fanvil X4G

  • Page 1: Table Of Contents

    Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Video Tutorial 3 Requirements 3.1 Identifying phone model 3.2 Phone firmware 3.3 DHCP server 3.4 PBXware version 4 Installation 4.1 Power adapter 4.2 Power over Ethernet (PoE) 4.3 Find the phone IP address 4.4 Reset to factory settings...

  • Page 2: Video Tutorial

    This Configuration Guide is written as general guide on how to configure the Fanvil phone model X4G to work with PBXware 4.1.3. Fanvil X4G supported features: Multiple VoIP accounts Auto provision via TFTP/HTTP/HTTPS Call hold, mute, DND Call forward, call waiting, call transfer...

  • Page 3: Requirements

    Make sure that your phone is loaded with appropriate firmware version, 2.2.0.3685. To find out the firmware version of your Fanvil phone model open a new browser window and enter your phone IP address in order to access the phone web administration interface login screen.

  • Page 4: Power Adapter

    Factory Settings Power adapter Connect the Network and Power Connect the DC plug on the power adapter to the DC port on the phone and connect the other end of the power adapter into an electrical power outlet. Connect the ethernet cable between the Internet port on the phone and the network port on a router or switch to access LAN.

  • Page 5: Registering Phone

    UAD settings Navigate to Settings:UAD. Make sure Fanvil UAD is enabled. To check the UAD status click on the edit icon corresponding to your Fanvil phone. Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
  • Page 6 Department to which extension will belong to. Example: Sales. Click on the Save button. Registering Phone This chapter describes how to register Fanvil phone using Hostname or IP Address. Hostname or IP Address Login to phone web administration interface Open a new browser window and enter your phone IP address in order to access the phone...

  • Page 7: Auto Provisioning

    Login to phone web administration interface with your username and password. Please note, factory default login details are username: admin and password: admin. Click on Line link in the left hand navigation menu Enter or set the following details into the respective fields. REQUIRED FIELDS: Username PBXware extension number.
  • Page 8 UAD settings. Navigate to Settings:UAD. Make sure Fanvil UAD is enabled. To check the UAD status click on the edit icon corresponding to your Fanvil phone. Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
  • Page 9 Click on the Save button. Registering Phone This chapter describes how to register Fanvil phone using TFTP & HTTP & HTTPS. TFTP & HTTP & HTTPS Open a new browser window and enter your phone IP address, e.g. http://192.168.1.22.
  • Page 10 If you choose to use Protocol Type HTTP or HTTPS enter http:// or https:// followed by Hostname or IP Address, followed then by /prov. Example for Hostname using HTTP: http://abc.bicomsystems.com/prov Example for Hostname using HTTPS: https://abc.bicomsystems.com/prov Example for IP Address using HTTP: http://192.168.1.10/prov Example for IP Address USING HTTPS: https://192.168.1.10/prov If you choose to use Protocol Type TFTP enter tftp:// followed by Hostname or IP Address...

  • Page 11: Configure Blf

    Configure BLF Extension Settings This chapter describes how to configure BLF (Busy Lamp Field) for Fanvil X4G. Login to PBXware web administration interface. Open a new browser window and enter the IP address in order to access the PBXware web administration login page.
  • Page 12 Open a new browser window and enter your phone IP address in order to access the phone web administration interface login screen. Example: http://192.168.1.22. Login to phone web administration interface with your username and password. Please note, factory default login details are username: admin and password: admin. Click on Function Key link in the left hand navigation menu Configure 1 to 12 DSS Keys from the list.
