CHAPTER 6: Technical Data

Dimensions
• Width 19'' (483 mm)
• Height 1 RU (44.5 mm)
• Depth 10'' (254 mm)
Weight
• about 3.4 kg
Power Consumption
• 25 W
Power Supply
• 84 V - 264 V AC / 47 Hz - 63 Hz / Safety class 1
Fuses
• Fuse 250 V - 2 A (slow-blow) – 2 fuses per power supply
Environmental Conditions
• Operating temperature +5°C up to +45°C
• Relative humidity: 10% - 80%, non condensing
MADI Port - (Version BNC/SC)
• 2 x BNC socket (1 x input / 1 x output)
• Impedance: 75 Ω
• 0.3 V up to 0.6 V (peak to peak)
MADI Port - (Version BNC/SC or SC/SC)
• 2 x or 4 x SC socket FDDI (input / output)
• ISO/IEC 9314-3
• Wave length: 1310 nm
• Multi mode 62.5/125 µm or 50/125 µm
• optional: single mode 9/125 µm
Sample Rate
• 32 kHz to 192 kHz
MADI Format (I/O)
• 48k Frame, 96k Frame
• 56 channel, 64 channel
• S/MUX 2/4
