page 14 of 24
4.
Connect the signal cables for the MADI signals to the device.
5.
Using the power cord provided connect the PSU to a matching power supply.
WARN ING
This device must be connected to the mains using the three-cord power leads
supplied with the system. Only supply the voltages and signals indicated (84 V –
264 V).
N OTE
This device may operate with only one power supply. To provide power supply
redundancy, it is recommended to connect both PSU 1 and PSU 2 to independent
power supplies with separate fuses.
6.
Turn on the power switch and check the status of PSUs on the front panel:
T I P
Keep any packaging in order to protect the device should it need to be dispatched
for service.
CHAPTER 3: Installation
SPLIT.CONVERTER Manual - Version 2.0
