CHAPTER 4: Operation
Global Control
The control on the right of the front panel indicates the power supply. Power
switches are on the back panel:
PSU 1 & PSU 2 (rear)
PSU 1 & PSU 2 (rear)
PSU 1 & PSU 2 (front)
NOT E
The green LEDs (PSU 1 & PSU 2) indicate that a working power supply is
connected to the power supply unit. Note that an unlit LED does not guarantee
that the device is free of voltage. To ensure that the device is completely
disconnected from mains voltage, the power chords must be disconnected.
2 Switches
Enable / disable power supply.
C13 socket
Connect the power supply here (84 - 264 V AC).
2 LEDs (green): indicate the status of both
power supply units
LED OFF = Power supply inactive
LED ON = Power supply active
SPLIT.CONVERTER Manual - Version 2.0
