CHAPTER 3: Installation
Installing the Device
1.
Open the packaging and check that the contents have been delivered
complete and undamaged.
2. Fix the device in a 19'' frame with four screws, or place it on a non-slip
horizontal surface.
WA R NI NG!
Avoid damage from condensation by waiting for the device to adapt to the
environmental temperature. Proper operation can only be guaranteed between
temperatures of 5º C and 45º C and a maximum relative humidity of 80%, non-
condensing.
Ensure that the unit has suffi cient air circulation for cooling.
3.
Remove the protective cap from the optical MADI port(s) before use.
BNC / SC Version
BNC / SC Version
BNC / SC Version
BNC / SC Version
(Version BNC / SC)
(Version SC / SC)
N OT E
Retain the protective cap if the optical port is unused. This will protect against
soiling which can lead to malfunction.
SPLIT.CONVERTER Manual - Version 2.0
SC / SC Version
SC / SC Version
SC / SC Version
SC / SC Version
CHAPTER 3: Installation
page 13 of 24
