FEV1 or PEF > 80%
FEV1 or PEF > 50% < 80%
FEV1 of PEF < 50%
These default values can be modified by the doctor during the configuration process.
1.7 Technical specifications
The following is a complete description of the technical characteristics of the instrument and of the flow/volume and
Pulse Oxymeter sensors.
1.7.1 Spirometer specifications
Measured parameters:
FVC Forced Vital Capacity
FEV1 Volume expired in the 1st second of test
FEV1% FEV1/FVC x100
PEF Peak Expiratory Flow
FEF2575 Average flow between 25% and 75% of the
FVC
FET Forced expiratory time
Flow/Volume sensor:
Measuring method:
Max volume:
Flow range:
Volume accuracy:
Flow accuracy:
Dynamic resistance at 12 L/s:
1.7.2 Pulse oximeter specifications
Measured parameters:
%SpO2 Oxygen Saturation
Pulse Rate
♥
Pulse oximeter sensor:
The sensors intended to use with Spirodoc are:
• BCI 1300 Adult Disposable Sensor
• BCI 3026 Neonatal Wrap Sensor
• BCI 3043 Universal Y Sensor
•
BCI 3078 Ear Sensor
•
BCI 3178 Pediatric Reusable Finger Sensor
•
BCI 3444 Adult Reusable Sensor – Comfort Clip
•
BCI 3044 Adult Reusable Finger Sensor
These sensors require the use of an extension cable cod. 919100_INV to be correctly connected to the
device.
The same sensors are also available with microconnector for the direct connection.
Measuring method: Red and Infrared absorption
%SpO2 range: 0-99% Functional SpO2 (1% increments)
%SpO2 accuracy: Adult: 2 @70-100% SpO2, less than 70% is undefined
%SpO2 averaging: 8 beats
Pulse Rate range: 30-254 BPM (1 BPM increments)
2 BPM or 2% whichever is greater
Pulse Rate accuracy:
Pulse rate averaging: 8 seconds
Signal strength: 0 - 8
Audible warnings:
• Pulse Beep, at the frequency of the cardiac pulse
• Continuous beep, if the %SpO
• Continuous beep during the oximetry test, if the battery is low
Displayed warnings:
•
Insert the finger
•
Connect sensor
1.7.3 Other specifications
spirodoc user manual code 980165
Green: No problem
Yellow: Caution
Red: Alert, contact doctor
L
L
%
L/s
L/s
s
Bi-directional turbine
Infrared interruption
10 L
16 L/s
3% or 50 mL
5 % or 200 mL/s
<1 cmH O/L/s
2
%
Beats Per Minutes (BPM)
limit values or the pulse rate go outside of the set limits
2
Rev 4.5 page 8 of 27
