LEVEL COLOUR FUNCTIONAL INTERPRETATION
0 Green
1 Yellow Mild Obstruction
2 Yellow-Orange Moderate Obstruc
3 Orange Mod.Severe Obst
4 Light Red Severe Obstruction Severe Restriction
5 Dark Red Very Severe Obst
In the case of a "mixed" interpretation (obstruction plus restriction) then the colour code will always refer to the more
severe of the two pathologies.
3.2

Viewing the results

When the subject details have been inserted and at least one spirometry test made, then the symbol " " is shown next to
the FVC to indicate that the results are held in memory:
Select fuction
SUB FVC SpO
In the event that the same patient makes also an oxymetry test then the same symbol " " is shown next to the SpO
and indicates that an oxymetry test is held in memory:
Select fuction
SUB FVC
Press and on the display the following are shown, in order:
• the spirometry parameters of the best test
FVC
FEV1
FEV %
1
PEF
2575
FET
• the minimum, maximum and average values of SpO
Min Max Ave SpO
96 99
Min Max Med BPM
62 105
If the message:
No test data
in memory
Is shown, this means that no tests have been made since the new subject data were entered.
3.3 Print out of the results
To print the results held in memory, connect the spirodoc to a parallel printer and press the " " key from the main menu.
The results are then sent automatically to the printer.
WARNING
To make a print out of the results then the optional hardware (Optoisolated RS232 interface plus serial to
parallel converter).
To connect to the printer see the following illustration.
spirodoc user manual code 980165
Normal spirometry
Mild Restriction
Moderate Restric
Mod.Severe Rest
Very Severe Rest
2
SpO
2
4.82 89%
4.12 91%
85.8 99%
9.42 91%
4.02 82%
5.72
and of the pulse rate from the last test made
2
2
98,3 %
88
Rev 4.5 page 16 of 27
