The current date format (dd/mm/yy or mm/dd/yy) is shown on the second line. To modify the date format see the
section describing the configuration menu.
• Use " ∆ ∆ ∆ ∆ " and " ∇ ∇ ∇ ∇ " to increase or to decrease the value of the selected field.
•
Press " " to return to the previous field, to correct an error.
• Press "↵ ↵ ↵ ↵ " to confirm each value.
When the date is set the screen shows (for example):
DATE 22 / 01 / 04
TIME 16
Use the same procedure to set the time.
If the device was purchased with the oximetry option, the following screens are shown:
•
the upper and lower limit values of the %SpO
for the %SpO and for the pulse (in bpm), are then shown:
2
•
the current setting (on or off) of the acoustic signal
WARNING
During the oximetry measurement, if the value of the %SpO2 or of the pulse rate go outside of the threshold
values, then spirodoc emits an audible warning which continues as long as the conditions remain.
The default threshold values are shown.
If the optional oximetry module has not been purchased with the spirodoc then only spirometry testing can be carried
out.
If the following message is shown:
this means that your device has the oximetry option fitted but this function has not been activated. In this case contact the
manufacturer or an authorised service agent.
The device can be switched off at any time by pressing and holding down the "↵ ↵ ↵ ↵ " for a few seconds.
After 3 minutes the device will automatically switch off.
2.4

Entering subject data

From the main menu select SUB :
To insert details of a new subject press the New key.
To keep these subject details (ie to retest that subject) press Esc :
Age cm kg
35 172 74
To keep these subject details (ie to retest that subject) press "↵ ↵ ↵ ↵ ". To insert details of a new subject press the " " key
2.4.1 New subject data
The cursor is shown " " against the first parameter (age). Use the keys " ∆ ∆ ∆ ∆ " and " ∇ ∇ ∇ ∇ " to select the correct age .
Age cm
35 172 74
spirodoc user manual code 980165
33 : 15
and of the pulse rate (in bpm)The max and min threshold values, both
2
%SpO 80/100
2
BPM 40/180
BEEP ON/OFF
On
Oximetry
disabled
Subject data
New
S #
001
kg S #
001
Rev 4.5
Off
Esc
