The " i " key is used to return to view some info messages.
2.2

Battery level

The symbol indicates the level of the battery is charge. The maximum charge of the batteries is indicated when four
symbols appear. As the battery charge level reduces the symbol
If the battery is completely discharged the following message is shown on the display:
LOW BATTERY
WARNING
If the "battery discharged" condition occurs during an oximetry test then spirodoc emits a constant beep
(providing this function is switched on!)
2.3 To make a test
Switch on the spirodoc by pressing the "↵ ↵ ↵ ↵ " key
The following message is shown, the charge of the battery and the percentage of memory remaining are displayed:
BATTERY
Free memory 95%
If no tests or information have been stored the following message is shown:
BATTERY
Memory
After circa one second the main menu is shown:
Select function
SUB FVC
SUB to insert the new subject's data
FVC to make a spirometry test
SpO to make an oximetry test
2
to view or to print the test results
If " i " key is pressed the following info messages are shown:
spirodoc
Ver x.y
The product name is indicated on the first line and the current software version on the second line.
After circa one second, the charge of the battery and the percentage of memory remaining are displayed:
BATTERY
Free memory 95%
After circa two seconds the current date and time are shown:
DATE 20 / 01 / 04
TIME 16 : 48 : 55
When the date and time are shown, press the " " key to modify the date and time:
DATE 20
dd / mm / yy
The arrow shown to the right of the field indicates the value to be modified.
WARNING
spirodoc user manual code 980165
empty
SpO
2
01 / 04
Rev 4.5
is shown.
.
