- Page 1 Goboceptor User Manual Order code: EQLED066...
-
Page 2: Safety Advice
NO USER SERVICEABLE PARTS. pulling the power-cable. • This lighting fixture is for professional use only - it is • Make sure that the available mains supply voltage is not designed for or suitable for household use. The between 100~240V AC, 50/60Hz. product must be installed by a qualified technician in accordance with local territory regulations. The safety of • Make sure that the power cable is never crimped or the installation is the responsibility of the installer. The damaged. Check the equipment and the power cable fixture presents risks of severe injury or death due to fire periodically. hazards, electric shock and falls. • If the equipment is dropped or damaged, disconnect the • Warning! Risk Group 2 LED product according to mains power supply immediately and have a qualified EN 62471. Do not view the light output with optical engineer inspect the equipment before operating again. instruments or any device that may concentrate the beam. • WARRANTY: One year from date of purchase. OPERATING DETERMINATIONS If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and/or property. www.prolight.co.uk Goboceptor User Manual... - Page 3 Product overview & technical specifications Goboceptor Three effects in one. This room filling derby effect has been combined with a gobo wheel to produce a multitude of colour changing beams. Adding even more to the mix are 8 x 3W UV floods and 2 x 3W strobes all in a compact housing. • 8 x 3W LEDs (R: 2, G: 2, B: 2, A: 2) plus 8 x 3W UV LEDs and 2 x 3W white LEDs with strobe and wash effects • DMX channels: 2 or 7 selectable • Auto, sound active and master/slave modes • 0 - 100% dimming and variable strobe • Supplied with hanging bracket • 4 push button menu with LED display • IEC power input/output • 3-Pin XLR input/output • Fan cooled • Supplied with IR remote Specifications Power consumption Power supply 100~240V, 50/60Hz Fuse T2A 250V Dimensions 192 x 230 x 245mm Weight Order codes EQLED066 230mm 245mm www.prolight.co.uk Goboceptor User Manual...
-
Page 4: Technical Specifications
Technical specifications 01 - LED display 02 - Function buttons 07 - Fuse T2A 250V In the box: 1 x fixture, 03 - 3-Pin DMX input 08 - On/off switch 1 x IR remote, 04 - 3-Pin DMX output 09 - Safety eye 1 x power cable 05 - IEC power input 10 - Hanging bracket & 1 x user manual 06 - IEC power output 11 - Hanging bracket adjustment knobs www.prolight.co.uk Goboceptor User Manual... -
Page 5: Master/Slave Mode
E S t Test mode d I S P d I S P Display invert d S I P F h r S Fixture hours u E r Software version r S E t Reset www.prolight.co.uk Goboceptor User Manual... -
Page 6: Operating Instructions
Show 4 (Shows 1-3 random) 000-247 Show 1-4 speed (slow-fast) 000-009 RGBA LEDs off 248-255 Show 1-4 sound active 010-198 Colour selection Colour change single colour 199-225 (slow-fast) 226-255 Colour change (slow-fast) 000-009 No function 010-244 Strobe (RGBA LEDs slow-fast) 245-255 Strobe (RGBA LEDs sound control) 000-127 Gobo positioning 128-255 Gobo scanning (slow-fast) 000-255 White LEDs dimmer (0-100%) 000-244 Strobe (White LEDs slow-fast) 245-255 Strobe (White LEDs sound control) 000-255 UV LEDs dimmer (0-100%) 000-244 Strobe (UV LEDs slow-fast) 245-255 Strobe (UV LEDs sound control) www.prolight.co.uk Goboceptor User Manual... - Page 7 SLAv “UP” and “DOWN” buttons to choose . Press the “ENTER” button to confirm the setting. The unit will now run in sequence with the master unit. To exit out of any of the above options, press the “MENU” button. Please ensure that all slave units are set to the same DMX channel mode as the master unit. Sound active: To access sound active setting, press the “MENU” button and use the “UP” and “DOWN” buttons on the SoUn rear of the unit to show on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose between or . Press the “ENTER” button to confirm the setting. To exit out of any of the above options, press the “MENU” button. Sound sensitivity: To adjust the sound sensitivity, press the “MENU” button and use the “UP” and “DOWN” buttons on the SoSE rear of the unit to show on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose between . Press the “ENTER” button to confirm the setting. Value: 0 - 100 (0 = low, 100 = high) To exit out of any of the above options, press the “MENU” button. www.prolight.co.uk Goboceptor User Manual...
- Page 8 To exit out of any of the above options, press the “MENU” button. Display invert setting: To access the display invert setting, press the “MENU” button and use the “UP” and “DOWN” buttons on dISP the rear of the unit to show on the LED display. Now press the “ENTER” button and use the “UP” dISP dSIp and “DOWN” buttons to choose between or . Press the “ENTER” button to confirm the setting. To exit out of any of the above options, press the “MENU” button. Fixture hours: To access the fixture hours, press the “MENU” button and use the “UP” and “DOWN” buttons on the rear FhrS of the unit to show on the LED display. Now press the “ENTER” button and the fixture hours will be displayed. To exit out of any of the above options, press the “MENU” button. Software version: To access the software version, press the “MENU” button and use the “UP” and “DOWN” buttons on the rear of the unit to show on the LED display. Now press the “ENTER” button and the software version will be displayed. To exit out of any of the above options, press the “MENU” button. Reset: To access the reset setting, press the “MENU” button and use the “UP” and “DOWN” buttons on the rear rSEt of the unit to show on the LED display. Now press the “ENTER” button and the unit will start to reset. Please note: the LED display will go off during this time and will come back on after 15 seconds once the reset has been performed. To exit out of any of the above options, press the “MENU” button. www.prolight.co.uk Goboceptor User Manual...
- Page 9 Operating instructions IR remote functions: Button functions: 01 - Sets the unit into blackout on or off 02 - Sets the unit into the chosen show mode - Use the ‘Speed’, ‘Speed -’ and ‘Speed +’ buttons to select the desired speed. 03 - Allows a colour to be selected 04 - Selects a random colour 05 - Puts the unit into sound active mode on 06 - Puts the unit into sound active mode off 07 - Increases the selected show speed 08 - Decreases the selected show speed 09 - Sets the selected show speed at a medium speed www.prolight.co.uk Goboceptor User Manual...
-
Page 10: Dmx Setup
DATA cable (DMX cable) requirements (for DMX operation): This fixture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit. Your unit and your DMX controller require a standard 3-pin XLR connector for data input/output, see image below. Further DMX cables can be purchased from all good sound and lighting suppliers or Pro Light Concepts dealers. Please quote: CABL10 – 2m CABL11 – 5m CABL12 – 10m Also remember that DMX cable must be daisy chained and cannot be split. www.prolight.co.uk Goboceptor User Manual... -
Page 11: Line Termination
5-pin XLR (socket) 3-pin XLR (socket) Pin 1: GND (screen) Pin 1: GND (screen) Pin 2: Signal (-) Pin 2: Signal (-) Pin 3: Signal (+) Pin 3: Signal (+) Pin 4: N/C Pin 5: N/C www.prolight.co.uk Goboceptor User Manual... -
Page 12: Weee Notice
WEEE notice Correct Disposal of this Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed of with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. www.prolight.co.uk Goboceptor User Manual...
