7. File Retreival
1. USB Cable Connection:
(A) Connect Micro USB Cable Hub to the DVR.
(B) Connect Mini USB cable to Micro USB Cable Hub to computer.
(C) DVR is read as External Storage from computer.
(D) Access the external storage, find the "Record" folder.
(E) Operate file applications in this folder.
2. Card Reader:
(A) Remove MicroSD card from card slot.
(B) Connect a card reader to the computer.
(C) Insert MicroSD card into the card reader.
(D) Access the card reader folder.
(E) Operate file applications in this folder.
8. File Playback
1. Video File Playback:
(A) Go to Main Menu > Video
(B) Press Navigation Button to access "Record" folder.
(C) Press Navigation Button to playback video.
(D) Move Navigation Button to right to fast forward.
(E) Move Navigation Button to left to play backward.
(F) Press ESC button to move to previous directory.
2. Image File Playback:
(A) Go to Main Menu > Images
(B) Press Navigation Button to zoom in and zoom out.
(C) Move Navigation Button up or down to view other files.
(D) Press Menu Button to edit Slideshow option.
5
9. Changing The Video System
1. Navigate to: Main Menu > Setting > Digital Cam NTSC/PAL
2. Press Navigation Button to access selection.
3. Move Navigation Button UP and Down to change the setting.
4. Move Navigation Button to left to exit setting edit.
5. Press ESC Button to exit Setting Menu page.
10. Continuous Recording
1. Navigate to: Main Menu > Record > Preview
2. Captured images will show on the screen.
3. Switch to REC position to start recording.
4. Device will start recording continuously when REC is switched.
5. Switch to the STOP position to stop recording.
11. Pre-event Recording
1. Navigate to: Main Menu > Record > Pre-event
2. Captured images will show on the screen.
3. Switch to REC position to start recording.
4. Device will automatically start recording 30 seconds before REC
is pressed.
5. Switch to STOP position to stop recording.
12. Motion Detect Recording
1. Navigate to: Main Menu > Settings > Motion Detection
2. Make changes on Motion Detection Level, Motion Detection
Duration, Motion Detection Zones, and Overwrite settings.
3. Navigate to: Main Menu > Settings > Recording Mode.
4. Select Motion Detect as default recording mode.
5. Switch to REC position to start recording.
6. Switch to Stop position and press ESC button for 3 seconds to
stop.
6
13. Password Protection
1. Power On Password:
(A) Navigate to: Main Menu > Setting > Set Power On Password
(B) Use Navigation Button to change password characters.
(C) Navigate to: Main Menu > Setting > Power On Password > On
2. USB Connection Password:
(A) Navigate to:
Main Menu > Setting > Set USB Connection Password
(B) Use Navigation Button to change password characters.
(C) Navigate to:
Main Menu > Setting > USB Connection Password > On
14. Timer Recording
1. Navigate to:
Main Menu > Setting > Timer Recording
2. Select any icon and edit timer settings.
3. Move to the end of the menu page.
4. Change Setting to On.
5. Turn the DVR power off.
6. DVR will start recording in response to the timer setting.
7
PV-900HD
Cellphone Design Portable DVR
Quick Guide
LawMate, innovation never stops
®
V1.3
