PV-RC200W
HD WI-FI Keyfob DVR (Black)
Quick Guide
A. Regarding the Device
1. Key Eject / Retract button
2. Power On/Off & REC Button
3. WI-FI On/Off & Client Button & WI-FI Reset
4. Snapshot Button
5. Memory Card Slot
6. Charge LED
7. USB Charge
8. Camera Lens
B. Power Charging
1) Press button 1 to eject key.
2) Connected the USB cable to 7 then connected the cable to USB Plug.
3) The 6 will showed Orange LED light on, The Orange LED light will off when the device is fully charged.
4) Hold down the 1 key and back depressed key.
C. Insert the SD Card
1) Place the SD Card into SD Card Slot, Press the SD Card
for take out the SD Card.
1
Advertisement
Related Manuals for Lawmate PV-RC200W
Summary of Contents for Lawmate PV-RC200W
- Page 1 PV-RC200W HD WI-FI Keyfob DVR (Black) Quick Guide A. Regarding the Device 1. Key Eject / Retract button 2. Power On/Off & REC Button 3. WI-FI On/Off & Client Button & WI-FI Reset 4. Snapshot Button 5. Memory Card Slot 6.
-
Page 2: Button Function
D. Button Function 1) Power On ： Hold the button 2 till it vibration, the device will vibration on 3 times. 2) Power On finish ： The device will vibration on 2 times when it finish power on. 3) Power Off ： Hold the button 2 till it vibration, the device will vibration on long times. 4) Power Off finish ：... - Page 5 APP UI description 1) Back to WI-FI which you need to connect device list. 2) Cell phone video and Photo archive folder. 3) SD card video host and Photo archive folder. 4) Setting. 5) Quick setting. 6) Host SD card resolution when recording. 7) SD card reminder.
- Page 6 Browsing Mobile Video and Photo Archive Information. 1) Film archives. 2) Photographic archives. 3) Film and photo all archive. 4) Mark archive what you need. 5) File name. 6) Mark all archive. 7) Unmark all archive. 8) Back to homepage. 9) Play button.
- Page 7 Browsing the Host SD Card Video and Photo Archive Information. 1) Film archives. 2) Photographic archives. 3) Film and photo all archive. 4) Continuous video file named beginning with Rec. otion detection recording named beginning with MRec. 6) Mark archive what you need. 7) File name.
- Page 8 WI-FI Setting 1) WI-FI host name. 2) WI-FI password *You may change the default password to your preferred here to keep the WIFI connection more confidential 3) Way of encryption. 4) WI-FI SSID invisible or not. 5) Host WI-FI off. 6) Back to homepage.
- Page 9 1) WIFI column option 2) Once power on, WI-FI is always on 3) WIFI turn off after 1 minute (If no connection detect) 4) WIFI turn off after 3 minute (If no connection detect) 5) WIFI turn off after 5 minute (If no connection detect) Once WIFI turn off it has to be switched on from the device, can’t be re-opened by the phone remotely 1) Privacy On/Off...
- Page 10 Image Setting 1) Play parameters. 2) Resolution. (D1、720P) 3) Frame choice. (10、15、20、25) Image Setting 1) Recording mode. Continuous recording / Motion detecting recording *When execute the motion record, after setting it up in The menu, it need to be pushed once for the either record button on the preview page to start to operate.
- Page 11 Date and Time Setting 1) Time display function ： White dot on the left ： Date display close. White dot on the right ： Date display open. 2) Date format. 3) Time format. 4) Synchronization with device time. 5) Confirm the setting. System Information 1) Card Memory Capacity.
- Page 12 1) Reset all setting. 1) Hot key for the spy mode page...
- Page 13 Go out from spy mode page by sliding it from right to left 1) Quick setting. 2) Resolution setting. (D1、720P) 3) Brightness setting. 4) Contrast setting. 5) Flip Top to Bottom. 6) Mirror left-right model. 7) Mic volume when recording.
