D302
Install Gooseneck
Dynamic Microphone
User Guide
G
O
A
N
G
-
F
A
N
N
C
O
.
,
L
T
D
.
© 2007, SUPERLUX I
LB100D30201EN (Rev. 1)
Specifications
Type
Dynamic Microphone
Polar pattern
Unidirectional (Super Cardioid), rotationally symmetrical about
microphone axis, uniform with frequency. (Figure 1)
Frequency response
100 to 10,000 Hz (Figure 2)
Sensitivity
(at 1,000 Hz Open Circuit Voltage)
-56dBV/Pa (1.58mV/Pa)
±3dB
1Pa=94dB SPL
Rated impedance
500Ω
Minimum load impedance
500Ω
Connector
Wire out
Finish
Metal construction with black painted finish
Environmental conditions
The D302 operates between -10℃ to +50℃(14℉ to 122℉) with
relative humidity between 0 to 95%.
Dimensions
Φ40.5mm(1.59in.) X 300.0mm(11.81in.), Figure 3
Net weight
150g (5.29oz.)
－1－
nc.
250 Hz
2000 Hz
500 Hz
4000 Hz
1000 Hz
8000 Hz
TYPICAL SUPERCARDIOID POLAR PATTERN (Figure 1)
F
r
e
q
u
e
n
c
y
R
e
s
p
o
n
s
e
dB
10
0
-10
-20
20
50
100
200
500
1000
2000
5000
10000
20000 Hz
F
R
E
Q
U
E
N
C
Y
I
N
H
z
TYPICAL FREQUENCY RESPONSE (Figure 2)
－2－
Dimen si ons (f igur e 3)
Description
The D302 conference style dynamic microphone, which is designed for
speech, conference, and vocal. Incorporating high sensitivity and wide
frequency response to precision sound pick up.
Simple mounting with tightening gaskets, to install the microphone onto a
podium or to fix with 5/8" nut on a base.
－3－
