SPECIFICATIONS
MODEL:
SIZE:
WEIGHT:
INPUT POWER:
TEST CURRENT:
PANEL DISPLAY:
FRONT PANEL:
INTERFACE:
MEMORY STORAGE: Stores up to 2000 complete test results
RESISTANCE RANGE :
MEASURING DUTY CYCYLE : 200A 10 min. on 5 min off. 100A & under continuous
MEASUREMENT PARAMETERS:
Current Range
200 Amp :
100 Amp :
50 Amp :
20 Amp :
10 Amp :
TEMPERATURE: Operating: - 10 C to 60 C
CABLE SET / ACCESSORIES
Current and potential lead set: 5 meters, Power cord: Heavy duty 7.6 meters, Instruction Manual,
Safety ground lead, RS-232 cable, cable carry case, extra roll of paper (5), spare fuses.
MC2 FEATURES:
• Automatic measurements of Low Resistance from 0.01 ...5
• Pure filtered DC Power source for the highest accuracy readings
• Microprocessor based system with internal storage for test results
• Single or continuous measurements with automatic data storage
• Automatic shut off for over-temperature condition
• Complete automatic calibration system and system diagnostics
• Internal Panel Mount Printer
• Centronics (Parallel) Interface & RS232 (serial) Interface
• 5 Year standard warranty
OPTIONS:
Part No - 2021A-05001 – 200 A Kelvin clip lead set, 5 meters
Part No - MC02 – Custom clamping devices (user specified)
Part No - 2021N-26001 – External Temperature probe, 10 meters
Part No - 2021N-15001 – Annual Warranty Extension
* Specifications are subject to change at anytime.
Raytech USA, Inc. All rights reserved
MC2
L: 20.5" (521 mm) W: 17" (432 mm) H: 8.5" (216 mm)
31.5 lbs. (14.4 kg)
100 to 250 Vac (1kW max.), 50/60 Hz, Automatic ranging
User Selectable: 200, 100, 50, 20, 10 Ampere
LCD Graphic with back lighting
Sealed anodized with a multi-actuation rotary knob
9 Pin RS232 Serial / 25 Pin Centronics Parallel
0.01 to 5 
Measuring Range
0.00  ... 20m
0.00  ... 40m
0.00  ... 100m
0.0  ... 1.0 
0.0  ... 5.0 
Accuracy
 0.1% Rdg  0.01  5 Digits or 0.01 
 0.1% Rdg  0.02  5 Digits or 0.02 
 0.1% Rdg  0.04  5 Digits or 0.05 
 0.1% Rdg  0.1 
 0.1% Rdg  0.2 
Storage: -20 C to 70 C
3 – 0
Highest Resolution
5 Digits or 0.1 
5 Digits or 0.2 
5
