iSolution ACME User Manual page 7

Lamp Temperature
Press the ENTER button and turn jog wheel until the Lamp Temperature
monitor. Pressing ENTER button and the ambient temperature of lamp will show on the
monitor. To go back to the main functions press the ESC button twice.
Lamp Hours
Press the ENTER button and turn jog wheel until the
Pressing ENTER button and the monitor will show the number of working hours of the unit. To
go back to the main functions press the ESC button twice.
Lamp On/Off
Press the ENTER button and turn jog wheel until the
monitor. Pressing ENTER button and the display will blink. Use jog wheel to select the (Lamp
on) or (Lamp off) mode. Once the mode has been selected, press the ENTER button to setup
or automatically return to the main functions without any change after 10 seconds. To go back
to the previous functions without any change press the ESC button.
Lamp On/Power On
Press the ENTER button and turn jog wheel until the
monitor. Pressing ENTER button and the display will blink. Use jog wheel to select the (on) or
(off ) mode. Once the mode has been selected, press the ENTER button to setup or
automatically return to the main functions without any change after 10 seconds. To go back to
the previous functions without any change press the ESC button.
Software Version
Press the ENTER button and turn jog wheel until the Software Version
monitor. Pressing ENTER button and the display will blink. Use jog wheel to select the (A) or
(B) or (C) or (D) mode. Once the mode has been selected, press the ENTER button to setup
or automatically return to the main functions without any change after 10 seconds. To go back
to the previous functions without any change press the ESC button.
Reset
Press the ENTER button and turn jog wheel until the
Pressing ENTER button and the display will blink. Use jog wheel to select the (Yes) or (No)
is shown on the
Lamp Hours is shown on the monitor.
Lamp On/Off is shown on the
Lamp On/Power On is shown on the
is shown on the
Reset is shown on the monitor.
12A
mode. select (Yes) option and all channels of the unit will return to their standard position. To
go back to the main functions press the ESC button twice.
4.3. Home Position Adjustment
Press the ENTER button for at least 5 seconds into offset mode, turn jog wheel until the
function is shown on the monitor pressing ENTER button again into the next function. Once
the function has been selected, use jog wheel to adjust this settings only for offset mode to
adjust home position. To go back to the previous functions without any change press ESC
button. The functions are shown below:
13A
