1. Safety Instruction

Please read carefully the instruction which include important
information about the installation, usage and maintenance.
WARNING
Please keep this manual for future consultation.
Unpack and check carefully there is no transportation damage before using the unit.
Before operating, be ensure that the voltage and frequency of power supply match the
power requirements of the unit.
The unit is designed for MSI 1200W/S, HMI 1200/S or HMQ 1200/S lamp (SFc10-4). Do
not use any other type of lamps.
It's important to ground the yellow/green conductor to earth to avoiding electric shock.
The unit is for indoors use in dry location.
The unit must be installed in a location with adequate ventilation, at least 50 cm from
adjacent surfaces. Be sure that no ventilation slots are blocked.
Disconnect main power before fuse/lamp replacement or servicing.
Replace fuse/lamp only with the same type.
Make sure there are no flammable materials close to the unit while operating, as it is fire
hazard.
Use safety chain when fixing this unit. Don't handle the unit by taking its head only, but
always by it's base.
Maximum ambient temperature is TA : 40℃. Don't operate it where the temperature is
higher than 40℃.
Unit surface temperature may reach up to 85℃. Don't touch the housing bare-hand
during its operation, and waiting for 15 minutes to cool down before replacing bulb or
serving, as the unit could be very hot.
Stop using the unit immediately when malfunction. Never try to repair the unit by yourself.
Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type
spare parts.
Don't connect the device to any dimmer pack.
Do not touch any wires during operation, as it might be a hazard of electric shock.
2A
Warning
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or
moisture.
Never touch bulb with bare fingers, as it is very hot after using.
Hot lamp explosion hazard. Do not open the unit within five minutes after switching off.
Do not start on the unit without bulb enclosure or when housing is damaged.
The housing, lenses or the ultraviolet filter must be replaced if they are visibly damaged.
The light beam will damage your retina, please do not look the light directly.
Caution
There are no user serviceable parts inside the unit. Do not open the housing or attempt
any repairs by yourself. If the unit need any require service, please contact your nearest
dealer.
Installation
The unit should be mounted via its mounting system on the bottom of the base. Use clamps to
fix the unit to truss. Always ensure that the unit is firmly fixed to avoid vibration and slipping
while operating. Always ensure that the structure to which you are attaching the unit is secure
and is able to support a weight of 50 kg for each unit.
1. Clamp
2. Safety cable
3. Quick-lock fastener
4.
Omega holder
3A
