TABLE OF CONTENTS 1. Safety Instruction 2. Technical Specification 2.1 Description of the fixture 3. Lamp 4. How to Set the Unit 4.1 Control Panel 4.2 Main Function 5.How to Control the Unit 5.1 DMX Controller 5.2 DMX 512 Configuration 5.3 DMX 512 Connection 6. -
Page 2: Safety Instruction
1. Safety Instruction Warning To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture. Please read carefully the instruction which include important Never touch bulb with bare fingers, as it is very hot after using. information about the installation, usage and maintenance. -
Page 3: Technical Specification
2. Technical Specification DMX Channels : (control by any universal DMX controller) 22 Channels Mode 16 Channels Mode Power supply - AC 208V/230V/240V/250V ~50Hz Channel 1 = pan Channel 1 = pan Lamp Channel 2 =Tilt Channel 2 =Tilt - MSI 1200W/S / HMI 1200/S / HMQ 1200/S SFc10-4 Channel 3 =pan/Tilt speed Channel 3 =pan/Tilt speed Optical system... -
Page 4: Description Of The Fixture
2. Lamp 2.1. Description of the fixture In case of replacement of the lamp or maintenance, do not open the fixture when power off it within 15 minutes. Moving head WARNING Yoke Tilt lock button (red) Because of its high internal pressure, there might be a risk that the Discharge lamp would Tilt unlock button (green) explode during operation. -
Page 5: How To Set The Unit
4. How To Set The Unit 6. If changing the lamp, remove old lamp from lamp socket. Hold the new lamp only by its ceramic base. Never touch the glass bulb. Insert the new lamp in the lamp socket. 4.1 Control Panel 7. -
Page 6: Main Function
4.2 Main Function Channel Mode Press the ENTER button and turn jog wheel until the Channel Mode is shown on the monitor. To select any of the pre-set functions, press the ENTER button and turn jog wheel until the required one is shown on the monitor. Select the function by ENTER button. Use the jog wheel Pressing ENTER button and the display will blink. - Page 7 Lamp Temperature mode. select (Yes) option and all channels of the unit will return to their standard position. To Press the ENTER button and turn jog wheel until the Lamp Temperature is shown on the go back to the main functions press the ESC button twice. monitor.
-
Page 8: How To Control The Unit
5. How To Control The Unit 5.2 DMX 512 Configuration The unit can be operating by any universal DMX controllers. 16 Channel Mode No need to turn the unit off when you change the DMX address, as new DMX address setting will be effected at once. -
Page 9: Dmx512 Connection
22 Channel Mode : 5.3. DMX512 Connection (Same configuration as ch. 1 to 16 of 16 channel mode) The fixture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output. The sockets are wired in parallel. Only use a shielded twisted-pair cable designed for RS-485 and 3-pin XLR-plugs and connectors in order to connect the controller with the fixture or one fixture with another. -
Page 10: Troubleshooting
Troubleshooting E. If The pan belt is broken Following are a few common problems that may occur during operation. Here are some 1. Turn off the main power. suggestions for easy troubleshooting: 2. Unscrew all the screws (A) and open the base-housing cover (B). -
Page 11: Fixture Cleaning
Pay attention to the belt tension when install the belt. Please refer to the photos below: Photo 1 : Adjust belt tension through loose this screws (D) Photo 2 : Adjust belt tension through loose this screws (D) 7. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output.
