Summary of Contents for iSolution DMX512
-
Page 1: Table Of Contents
TABLE OF CONTENTS 1. Safety Instruction 2. Technical Specification 3. Lamp 4. How To Set The Unit 5. How To Control The Unit 6. DMX512 Configuration 7. DMX512 Connection 8. Troubleshooting 9. Fixture Cleaning User Guide Широкий ассортимент оборудования ACME Professional Entertainment Technology на... -
Page 2: Safety Instruction
1. Safety Instruction Warning To prev ent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture. Please read caref ully the instruction, which includes important inf ormation Nev er touch bulb with bare fingers as it is v ery hot after using. about the installation, usage and maintenance. -
Page 3: Lamp
2.1 Beam Angle 3.1 HID 150W Lamp Installation Or Replacement IM-200S-ELC IM-200S-HID • Alway s switch power off before installing or replacing the lamp. Never try to replace the lamp when it is hot. • Do not touch the bulb with bare hands. Cleaning the lamp with denatured alcohol and wipe with a lint f ree cloth when lamp is dirty. -
Page 4: How To Set The Unit
Pressing ENTER f unction. button and the display will blink. Use DOWN and UP button to change the DMX512 address. Sensitivity Once the address has been selected, press the ENTER button to setup or automatically To adjust the sound receiv ing sensitivity return to the main functions without any change after 8 seconds. - Page 5 Channel Mode Blackout Mode Press the MENU button up to when the is shown on the display. Pressing ENTER Press the MENU button up to when the is showing on the display. Pressing button and the display will blink. Use DOWN and UP button to select the (8 Channel) or (11 ENTER button and the display will blink.
-
Page 6: How To Control The Unit
5. How To Control The Unit program. Back to the f unctions press MENU button again. You can operate the unit in three way s: Master Mode 1. By master/slav e built-in preprogram f unction 2. By easy controller Press the MENU button up to when the is showing on the display. -
Page 7: Dmx512 Configuration
Press the MENU button up to when the is showing on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to change the DMX512 address. Once the address has been selected, press and keep ENTER button pressed up to when the display stops blinking or storing automatically 8 seconds later. -
Page 8: Dmx512 Connection
7. DMX512 Connection The DMX 512 is widely used in intelligent lighting control, with a maximum of 512 channels. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit. -
Page 9: Troubleshooting
8. Troubleshooting G. If The pan belt is broken Turn off the main power. Following are a few common problems that may occur during operation. Here are Unscrew all the screws and open the base-housing cover. some suggestions for easy troubleshooting: Unplug all the connect wires that from the arm. -
Page 10: Fixture Cleaning
9. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the env ironment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
