Predator Automatic Scrubber 28
OPERATORS MANUAL AND PARTS LIST
Model PAS28
Contains drawings for all PAS28 models to date
WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL COMPLETELY
BEFORE OPERATING THIS EQUIPMENT.
PAS202

Advertisement

loading
Need help?

Need help?

Do you have a question about the PAS8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Powr-Flite PAS8

Summary of Contents for Powr-Flite PAS8

  • Page 1 Predator Automatic Scrubber 28 OPERATORS MANUAL AND PARTS LIST Model PAS28 Contains drawings for all PAS28 models to date WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE OPERATING THIS EQUIPMENT. PAS202...

  • Page 2: Technical Characteristics

    TECHNICAL CHARACTERISTICS POWR-FLITE ® PREDATOR™ 28 AUTO SCRUBBER MODEL PAS28 Technical Specifications U.S. Standard Metric Area per hour ..... . .44,000 sq. feet ......4088 sq. meters Solution Tank .
  • Page 3 POWR-FLITE PREDATOR 28 AUTOMATIC SCRUBBER This manual refers to a battery powered automatic floor scrubber. Designed to be simple, easy to operate and safe, with maneuver- ability and automatic variable electronic drive. Routine maintenance has been simplified and reduced to the minimum to keep equipment on the job.
  • Page 4 120 Volt 60 Hz Solution Tank: The solution tank is located under the lid, at Battery installation and charging: The batteries are sup- the front of the machine, with the filling-funnel M1 in an acces- plied separately and must be inserted in the special compart- sible position for easy re-filling.
  • Page 5 The area to be scrubbed: Debris and grit must be swept up CAUTION: Make sure key switch is in the “OFF” position before installing pad. before starting the scrubbing operation to avoid vacuum line blockage and to permit the detergent to perform efficiently. Particularly dirty floors: Certain floors or areas may require special attention and, in some cases, cleaning twice.
  • Page 6 Squeegee: Every week, check the blades of the squeegee and The machine is supplied with a pad driver. Brushes in tynex, wash them carefully. Then replace them in the correct working poly and steel are available on request, together with floor pads position (see above).
  • Page 7 WARNING! Do not operate machine or charger in areas where flammable liquids or gases are present. Do not use or pick up flammable chemicals or liquids with this machine. CAUTION: Make sure all caution, warning and instructional decals are in place and legible.

  • Page 8: Spare Parts

    SPARE PARTS Model PAS28 with serial number including 05-97-01616 and under Pos Part No. Description Pos Part No. Description Pos Part No. Description PAS 122 Hook 40 PAS 64 Knob 20 500.136 Split ring 700.002 Shaped 41 500.136 Split ring 21 PAS 190 Screw 700.003...
  • Page 9 SPARE PARTS Model PAS28 with serial number above 05-97-01616 Pos Part No. Description Pos Part No. Description Pos Part No. Description PAS 122 Hook 430.118 Washer PAS 14 Tie rod 700.002 Back Frame 500.136 Lockwasher PAS 64 Pedal cover 700.003 Yoke PAS 190 Screw...
  • Page 10 Pos Part No. Description Pos Part No. Description Pos Part No. Description 500.162 Pressure spring 430.072 Screw PAS 167 Screw 650.112 Right support PAS 5 Coupling, half 650.113 Lower lever 650.105 Spring support PAS 101 Key, machine PAS 14 Foot Cover PAS 4 Geared motor PAS 65...
  • Page 11 Part No. Description Part No. Description F909 Screen/Filter PAS 70 Seal 500.068 Float support (°) PAS 71 Fixed flange 500.094 Float (°) PAS 72 Seal PAS 103 Seal (°) PAS 73 Movable flange (°) PAS 17 Complete float PAS 186 Washer PAS 80 Intake hose...
  • Page 12 Part No. Description Part No. Description Part No. Description 700.135 PAS 11 Knob 400.161 PAS 805 Solution tank 700.158 Support PAS 12 Solution Valve PAS 3 Filter 430.056 Screw 500.056 Split pin 700.138 Hinge 700.160 Hook and cord PAS 146 Washer 700.139 Hose...
  • Page 13 Pos Part No. Description Pos Part No. Description Pos Part No. Description PAS 148 Dowel 430.025 PAS 176 430.297 Washer 850.444 Support 850.446 Square 430.299 Screw PAS 146 Washer 430.173 Screw 700.182 Screw PAS 223 Screw 500.136 Split ring 850.445 Spring PAS 56 Micro-switch...
  • Page 14 SPARE PARTS Model PAS28 with serial number 05-97-01616 and under Pos Part No. Description Pos Part No. Description PAS 86 Battery tray 650.328 Yoke 700.221 Component support 430.072 Screw PAS 87 Micro Processor PAS 54 Vac switch PAS 54 Brush switch PAS 119 6.3 Amp Fuse PAS 88...
  • Page 15 SPARE PARTS Model PAS28 with serial number over 05-97-01616 Pos Part No. Description Pos Part No. Description Microprocessor Diagnostic PAS 86 Battery tray 650.328 Yoke Signals 700.221 Component support 430.072 Screw The Model PAS28 with serial numbers PAS 87 Micro Processor PAS 54 Vac switch above 05-97-01616 have an on board...
  • Page 16 Model PAS28 with serial number 05-97-01616 and under LIGHT 1. WHITE/BLUE 2. WHITE/YELLOW 3. PINK 4. WHITE/BLACK 5. WHITE/GREEN 6. RED/BLACK LIGHT TRACTION MOTOR WHITE/BLACK BLACK BLACK/MAROON BLACK MAROON WHITE/BLACK 1. BLACK 2. WHITE/BLUE BLACK/MAROON 3. WHITE/YELLOW 4. RED/BLACK PINK 7.
  • Page 17 Model PAS28 with serial number above 05-97-0616 BATTERY LIGHT LIGHT GUAGE START BRUSH VACUUM SWITCH SWITCH FORWARD SWITCH REVERSE SWITCH — BATTERY SAFETY SWITCH VAC RELAY BRUSH RELAY SAFETY SWITCH 30 30 30 30 FUSE 6.3 AMP VACUUM MOTOR BRUSH MOTOR BRUSH MOTOR TRACTION MOTOR - 16 -...
  • Page 18 A Tacony Company 3101 Wichita Court • Ft. Worth, TX 76140-1710...
