Nikon Multizoom AZ100 Instruction Manual page 9

10
After observation, turn off the light source.
• After observation, turn off the light source and the lamp.
• If the microscope or the light source is to be covered by a dust cover, cool down the light source
sufficiently.
Bright-field microscopy under epi-illumination
4
Adjust the interpupillary distance
of the binocular part.
5
Adjust the diopters of the eyepieces.
9
Observe the specimen
under a magnification
adjusted by zoom operation.
7
Episcopic illumination:
Adjust the aperture diaphragm.
Diascopic illumination:
Adjust the condenser, the aperture
diaphragm, and the field diaphragm.
6
Place an objective into the optical path.
2
Set the specimen.
3
Turn on the light source
and adjust the brightness.
10
After observation,
turn off the light source.
Chapter 2 Microscopy
7
Set the optical path selector
to the binocular part position.
Focus on the specimen.
Adjust the position
of the specimen and then
focus on the specimen.
1
8
8
