Notes on Handling the System

1. Carefully handle the product.
This product is a precision instrument. Handle it carefully and do not subject it to damage or vibrations.
Especially, the accuracy of the objective may be adversely affected by even a slight damage.
Cautions in carrying the product
• Securely hold the bottom front of the microscope base and indentations at the bottom back of the
stage pillar when carrying the microscope.
• Do not grasp the stand pillar, elevating section, stage, stage height adjustment knob, focus knob,
eyepiece tube, or zoom body when carrying the microscope to avoid breakage, adverse effect on its
performance, or malfunctions.
2.
Installation or storage location
The microscope is a precision optical instrument. Using or storing the product under unsuitable
conditions may damage it or may have an adverse effect on its performance. The following conditions
must be considered when selecting the installation or storage location.
• For installation, select a location with a temperature from 0 to 40ºC and a relative humidity of 85 %
or less (no condensation).
For storage, select a location with a temperature from -20 to 60ºC and a relative humidity of 90% or
less (no condensation).
If the product is installed or stored in a location subject to high temperatures and humidity, mold or
condensation may form on the lens, resulting in lowered performance and possible damage to the
microscope.
• Avoid installing in a place exposed to direct sunlight, or directly under room lights or any other bright
place. The image quality deteriorates in bright surroundings because of the extraneous light entering
the objective.
• Install in a place with little dust and dirt.
• Install in a place with little vibrations.
• Install and store the product on a sturdy desk or table that can bear the weight of the product.
• Install the product in the location of 10 cm or more away from the surrounding walls.
• Do not install in the narrow space such as shelf or locker.
• Do not place anything on the product.
• Cover the product to avoid dust when storing.
3. Notes on handling optical parts
Scratch or dirt such as fingerprints on the optical parts such as lens or filter affects the viewing of the
image.
Carefully use the optical parts without scratching. If any dirt attaches to the product, clean it according
to Chapter 6, "Care and Maintenance".
4. Handling the stage height adjustment knob and focus knob
• Do not rotate the right and left stage height adjustment knobs or the focus knobs in opposite
directions to avoid damage. Do not rotate those knobs in such a way.
• Do not rotate the coarse focus knob further in the same direction after it comes in contact with the
limited position to avoid malfunctions.
5. Cover the vertical tube.
The eyepiece tube is equipped with the vertical tube. To keep out ambient light and dust, always attach
the provided cap to the vertical tube that is not currently in use.
