Revised: 5.23.16 Sargent and Greenleaf® USB Audit Lock 2.0 Operating Instructions 3006 Pivot Bolt & 3007 Direct Drive The Sargent & Greenleaf Audit Lock is designed to provide a high level of security combined with flexible features that allow multiple levels of control over normal operations.
Page 2
Notes: • The S&G USB Audit Lock 2.0 Operating System includes: Model 3006 USB Pivot Audit Lock and 3007 Direct Drive Lock Systems • The S&G USB Audit Lock 2.0 System is built using sophisticated electronic circuitry and is suitable for indoor use only.
1. General Information To open the lock, use the factory setting for PIN position 10, with PIN Code 10101010. Enter: 10101010 # and the lock should open. (If lock does not open and beep patterns were heard after pressing the # key, reference Section 1.1 About Your Locking System 2.3 “Beep Patterns”...
2.3 Beep Patterns Table A: Programmer Code Position The following table lists the beep patterns that will be heard when using the Activity Position Description USB Audit Lock 2.0 Beep 1 = Sound emitted when any single button is pressed Programmer Code Cannot open lock Beep 2 = Lower pitch than beep 1...
2.4 Opening the Lock 2.10 USB Flash Drive Time Delay - The lock may be programmed with a time delay from 0 - 99 minutes A connector port for a recommended USB flash drive is provided on the front of with an opening window of 1 minute to 10 minutes.
The audit trail can be downloaded to an approved USB flash drive and uploaded implemented for changes to take effect). to a computer using the Sargent and Greenleaf USB Drive Audit Lock Audit Trail Step 2 Enter: 0 0 1 2 3 4 5 6 # Software.
3.9 — Command 43: Identify Lock Mechanics Follow the instructions provided with the Sargent and Greenleaf Audit Trail Software to upload the data to your computer. Use this code to verify that the firmware version that has been loaded into the lock.
3.11 — Command 46: Setting Up the Time Delay 3.12 — Command 47: Setting up the Time Delay (cont.) Override Options (cont.) To eliminate the time delay period, simply enter zero (0) for the time Example… delay minutes. To enable TDO type 2: Step 1 Enter: 4 6 * 3.13 —...
3.15 — Command 56: Enable/Disable User Disable 3.17 — Command 67: Setting / Using MRC Function (cont.) Feature - Manager / employee mode (cont.) Example… Enable / Disable the User’s Ability to Disable the Lock To add an MRC with a value of 98765432: Step 1 Enter: 6 7* The ability to allow users to disable the lock (manager/employee mode only) by...
3.18 — Command 75: Adding Code Positions (cont.) 3.22 — Command 83: Disabling the Time Delay Override Feature Example... If you do not want the time delay override function available, it can be To add User position 20 with a code of 21212121 permanently disabled and all of the time delay override commands will no Step 1 Enter: 7 5 *...
4.1—Flash Drive Specification • Flash drive to be USB 2.0 certified and that meet MSD Class certifications. • Flash drive to be formatted to FAT32 file system. • Flash drive to be formatted with the Default Allocation Unit size for the drive capacity.
