Model 6120
Motorized Electronic
Combination Lock
The Sargent & Greenleaf Model 6120 combines ease of operation with security. Its advanced
electronic circuit design makes it easy to open and easy to change codes. Follow these
instructions carefully to get the best possible use from your lock.
I
NTRODUCTION
• The Sargent & Greenleaf Model 6120 Motorized Electronic Combination Lock is shipped from the
factory with a factory master code only. It is 1 2 3 4 5 6
and set or change all of its codes. If the safe maker or your dealer sets a new master code, he will
advise you of the change. You should set the lock to your own, unique master code immediately.
• The Model 6120 will always open on the master code. At your discretion, it can also be set to
accept up to eight different user codes. The master code holder is responsible for maintaining the
number of active users programmed into each lock. The master code is designated as code #1,
and the user codes (if set) are designated by user I.D. number 2, 3, 4, 5, 6, 7, 8, and 9. The
user codes do not exist until they are programmed into the lock.
• Each time a button is pressed and the lock accepts the input, it emits a "chirp," and the LED on the
keypad lights momentarily.
• All codes must contain six digits or six letters. Any digit or letter can be used as many times as you
wish. For instance, the following codes (while not recommended) will operate the lock:
5 5 5 5 5 5
• All codes end with
• If you pause more than 10 seconds between pressing buttons when entering a code, the lock will
assume you do not want to continue, and it will reset itself to the original code. To open the lock,
begin the code entry sequence from the first step.
• If you realize you have pressed an incorrect button when entering a code, press
ten seconds or more, then begin entering your code again.
• If four incorrect codes are entered in a row, the Model 6120 will shut down for a period of up to
fifteen minutes. This is a security feature. Pressing any button anytime during the lockout period will
resent the timer to its maximum penalty time. Do not touch any keypad buttons for a period of
fifteen minutes, then enter any valid code to open the lock.
• The model 6120 does not have audit trail capabilities.
Sargent & Greenleaf, Inc.
One Security Drive, Nicholasville, Kentucky 40356
Phone (800) 826-7652
Phone (859) 885-9411
Copyright 1993, Sargent & Greenleaf, Inc.
#
OR J J J J J J
#
. This signals the lock that you have finished entering all digits of the code.
FAX (800) 634-4843
FAX (859) 887-2057
Operating
Instructions
#
. This code is used to open the lock
#
Sargent & Greenleaf S.A.
9, chemin du Croset, 1024 Ecublens, Switzerland
Phone 41-21-691-9583
*
or simply pause
FAX 41-21-691-5349
This document is part number 630-302
Revision 2/10/03
