Model 6128/6129 and 6106-240 A-Series
Programming and Operations Guide
General Information
The Sargent & Greenleaf Models 6128, 6129 and 6106-240 are
designed to provide a high level of security combined with
fl exible features that allow multiple levels of control over normal
operations and service access. Follow these instructions
carefully to get the best possible use from your lock.
Introduction
• A-Series electronic safe locks incorporate sophisticated
electronic circuitry. These locks are suitable for indoor use only.
• The keypad should only be cleaned with a soft, dry cloth.
Avoid the use of solvents or liquids.
• Never attempt to lubricate the lock or keypad components.
Service should only be performed by a qualifi ed technician.
• Anytime the keypad is removed from its mounting base, either
disconnect the lock cable or support the keypad so that it does
not hang by the cable. This could adversely affect the cable
connector or the keypad receptacle.
• Each time a button is pressed, and the lock accepts the input, it emits a "beep," and the LED on the keypad lights momentarily.
• All the letters of the English alphabet are displayed on the keypad. This allows you to devise numeric, alphanumeric, or word-based
codes. Use whatever approach works best for you.
• All codes end with #. This signals the lock that you have fi nished entering all digits of the code.
• Personal data which can be directly related to a code holder, such as a birthdate, should not be used in making up a lock code.
Avoid codes which can be easily guessed.
• After the lock is changed to a new code, the lock function must be checked by locking and unlocking it several times with the
container door open. Make sure it functions correctly before closing the door.
Note: This lock has been Listed by Underwriters Laboratories for use with the following S&G keypad(s):
6120-0XX, 61KP-1XX, 61KP-2XX
1
Sargent and Greenleaf
Revision 02/15/2022 Document: 630-600
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sargent and Greenleaf 6128-240 A Series
Summary of Contents for Sargent and Greenleaf 6128-240 A Series
- Page 1 • After the lock is changed to a new code, the lock function must be checked by locking and unlocking it several times with the container door open. Make sure it functions correctly before closing the door. Note: This lock has been Listed by Underwriters Laboratories for use with the following S&G keypad(s): 6120-0XX, 61KP-1XX, 61KP-2XX Sargent and Greenleaf Revision 02/15/2022 Document: 630-600...
-
Page 2: Table Of Contents
3.10 Command 73: Set Date - Bank Mode Only ........................16 3.11 Command 74-76: Add or Delete User Positions ......................17 3.12 Command 77: PIN Position Verification ........................18 3.13 Command 78: Set Time - Bank Mode Only ........................18 Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... - Page 3 4.8 Using the Duress Alarm Feature ..........................23 4.9 Set Clock Calendar: ..............................24 Red Manager Key No Key 4.10 Reset Lockout: ................................24 4.11 Revoke Dispatcher: ..............................24 4.12 Add Dispatcher ................................24 4.13 Un-install Lock: ................................24 Sargent and Greenleaf Revision 02/15/2022 Document: 630-600...
-
Page 4: General Information
♪ The beeps are indicated in the examples by the symbol . For example, fi ve beeps ♪♪♪♪♪ are indicated by . Always wait for each set of beeps to end before entering another number or letter or you will interrupt the lock’ s instructions. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 5: Factory Default Settings
The “Lock Management System” controls Bank mode optional features and is used for programming Touch Memory Keys and generating one-time use codes. 1.3 — Factory Default Settings The 6128/6129 is shipped from Sargent & Greenleaf with factory default settings: • Bank Mode — enabled / no time restriction. • Multiple User Mode — enabled • Time Delay — zero (0) minutes • Duress — disabled • Audit download — enabled • Set Date / Time — enabled Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 6: Operating The Lock
Bank User Group is the factory default and is always active in each lock (unless disabled under Service Mode operation). The Bank User Group has an access hierarchy of Officers (PIN positions 01- 03), Administrators (PIN positions 04-09), and Users (PIN positions 10 - 29). See Tables A&B beginning on the next page for access privileges. Bank User Group can be configured to operate in three different User access modes. Multiple User mode — any valid code for the lock (other than the Programmer Code) can be used to open it. Manager / Employee mode — the Officers or Administrators enable/disable the access privilege of individual User Codes. When in this mode the officer and Administrator Codes do not open the lock. Dual Control mode— two independent User Codes are needed to open the lock. Officer and Administrator Codes can be used to open the lock in this mode. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 7: Pin Positions And Access Responsibilities
Used for initialization of Service Mode with commands 45 and 54. Used in conjunction with other codes for commands 00,32,38,46,47,48,73,78, and 83. Cannot open lock. Cannot add/delete other PIN Codes. Can change its own PIN code. Send duress alarm (when programmed). Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... - Page 8 10 - 29 Users • Open the lock • Start time delay (when programmed). • Send duress alarm (when programmed). • Provide second User Code for programming. • Change their own PIN Code. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600...
-
Page 9: Beeps Patterns
2.3.1— Additional Actions/Conditions for Bank Mode with Keypad Extension Action/Condition Tone & Keypad LED KEB LEDs Duration Touch key read/write error 1 brap Red (+ Amber if SM) 1 cycle Clock battery too low 2 brap Red/Green alternate cycles Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 10: Additional Actions/Conditions For Service Mode
During the opening window, the lock beeps twice every 6 seconds. ♪♪♪ You must now: Enter: Your 2-digit PIN and Your Your 6-digit User Code again # Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 11: Keypad Input Errors And Clearing The Lock
The Sargent & Greenleaf Lock Management System software must be installed on your computer before you can upload and use the audit trail information stored in your lock. For more instructions on downloading the audit trail. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 12: Programming The Lock In Bank Mode
3) Enter: Officer code +# ♪♪♪♪♪ 3) Enter: 02020202 # ♪♪♪♪♪ 4) Enter: 3 (Function Number) + #♪♪♪ 4) Enter: 3 # ♪♪♪ 5) Enter: 3 (Function Number) + #♪♪♪ 5) Enter: 3 # ♪♪♪ Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 13: Command 38: Setting The Duress Alarm Feature
2) Enter: Programmer Code + #♪♪♪♪♪ 2) Enter: 00123456 # ♪♪♪♪♪ 3) Enter: 0(function number) + # ♪♪♪ 3) Enter: 0 # ♪♪♪ 4) Enter: 0(function number) + #♪♪♪ 4) Enter: 0 #♪♪♪ Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 14: Command 42/43: Verify Lock Type
1) Set the date & time using the 73* command and 78* command. 2) Snap the Management touch key into the keypad extension receptacle. 3) Enter: 54* 00123456 # (default Programmer Code or the current Programmer Code). 4) The Amber “Mode” light on the keypad extension base will remain lit during the initialization process. 5) Upon the successful initialization, the Green “Status 1” indicator will flash and the keypad will emit three beeps. If the initialization fails the Red “Status 2” indicator will illuminate, and the lock will emit one long beep. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 15: Commands 46: Setup Time Delay Override
If the time delay has already been set, changes to the opening window and time delay duration can only be made during the opening window. I MPORTANT: Do not set the time delay until you have finished all other programming functions, or you will have to wait through the time delay before making any other programming If changes. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 16: Command 48: Set Opening Window Duration
2) Enter: 00123456 # ♪♪♪♪♪ 3) Enter: Officer code +# ♪♪♪♪♪ 3) Enter: 02020202 # ♪♪♪♪♪ 4) Enter: Date(ddmmyy) + #♪♪♪ 4) Enter: 180122 #♪♪♪ 5) Enter: Date(ddmmyy)+ #♪♪♪ 5) Enter: 180122 #♪♪♪ Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 17: Command 74-76: Add Or Delete User Positions
3) Enter: 13 # ♪♪♪♪♪ 4) Enter: #♪♪♪ 4) Enter: # ♪♪♪ 5) Enter: #♪♪♪ 5) Enter: # ♪♪♪ We recommend that each User change his or her PIN Code using Command 22. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 18: Command 77: Pin Position Verification
3 standard beeps. Enter: 8 2 * Wait for the lock to emit 3 standard beeps before removing the touch key. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 19: Command 83: Disable Time Delay Override
Enter: 93* on the lock keypad. Aseal 103968 1 high beep 1 low beep 3 high beeps 9 high beeps 6 high beeps 8 high beeps Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 20: Command 96: Battery Verification
2) Enter: Programmer Code + #♪♪♪♪♪ 2) Enter: 00123456 # ♪♪♪♪♪ 3) Enter: 1/0 (on/off) + #♪♪♪ 3) Enter: 1/0 (on/off) + # ♪♪♪ 4) Enter: 1/0 (on/off) + #♪♪♪ 4) Enter: 1/0 (on/off) + # ♪♪♪ Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 21: Service Mode Operation
The operation codes are eight digits in length and will be valid for only one use. If the operation code is not used, the code will expire at the end of the time window specified by the operator of the Lock Management System at the time the code was generated. Each operation code is specific to the lock being addressed, the user, his four-digit PIN code, the touch key being presented, the request being made, and the date and time the code is valid. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 22: Service Mode Operation Codes
• The programmable features that may be set with this code are: • Bank mode enabled or disabled. • Time window of operation for bank users if enabled. • Access to audit log through bank operations. Once the lock’ s bank mode process has been enabled, you will be able to open the lock using a valid officer, administrator or user code. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 23: Download Audit Log
5) User inputs new time on keypad in HHmm format and presses the # key 6) Lock responds with Green “Status 1” indicator and emits three audible beeps. 7) User inputs time on keypad (HHmm) and presses the # again to confirm 8) Lock responds with Green “Status 1” indicator and emits three audible beeps. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600... -
Page 24: Set Clock Calendar
This is a management only operation code that is used to return the lock to its default Bank Operating Mode. Once this operation code is successfully performed, no new Service Mode operations are possible until the lock is initialized for Service Mode again. Once the lock has been uninstalled, you will be able to open the lock using one of the default officer or user codes. Sargent and Greenleaf Revision 02/15/2022 Document: 630-600...
