Servicer Code
Printer Cannot Get Ready (Red LED Fast Blinking)
No Power
Booting Fail
Pixel Registration
Uniformity
TPH Pixel Fail
Density
Wrinkle
Printout Contamination
Scratch
Horizontal Line
Vertical Line
Debris
Chart Abnormal
Unsupported Ribbon
Ribbon Error
Print Fail
Skew
Artificial Case
Ribbon Jam
Bluetooth Error
Alien Object Inside
Others
Noise
Printer Off-Line
System Cooling
LCD No/Wrong Signal
CONFIDENTIAL
1. Update printer firmware.
2. Change the Printer Main Board.
1. Change the Power Board.
2. Change the Main Board.
1. Adjust BIOS booting sequency.
2. Reset BIOS.
3. Change the system CF card.
1. Change the Pinch Roller.
2. Change the Capstan Roller.
Change the TPH.
Change the TPH.
1. Adjust voltage of the Printer TPH Board.
2. Change the TPH Board.
3. Change the TPH.
1. Change the ribbon cartridge.
2. Adjust voltage of the Printer TPH Board.
3. Change the TPH
Clean
Clean
1. Change the TQL.
2. Change the Pinch Roller.
3. Change the Platen Roller.
4. Change the Printer Main Board.
5. Change the Bearing_Capstan.
1. Change the TPH.
2. Change the Printer Main Board.
1. Clean the Capstan Roller.
2. Clean the Pinch Roller.
1. Change/Reconnect the TPH Wire.
2. Change/Reconnect the Flat Cable.
3. Change the Bushing_Platen.
4. Change the Spring_Pinch.
5. Change the Printer Main BD.
Change the ribbon cartridge.
Change the ribbon cartridge.
1. Confirm the ribbon is finished. Change the ribbon cartridge.
2. Check connection of Ribbon LED and Sensor (left& right).
3. Change the Ribbon LED (left & right).
4. Change the Ribbon Sensor (left & right).
1. Change the Pinch Roller.
2. Change the Capstan Roller.
3. Change the Bushing_Platen.
4. Change the Spring_Pinch.
-
1. Clean
2. Check connection of Ribbon LED and Sensor (left& right).
3. Change the Ribbon LED (left & right).
4. Change the Ribbon Sensor (left & right).
1. Change the Bluetooth Dongle.
2. Change the Card Board.
Clean
-
1. Clean.
2. Lubricate.
1. Update printer firmware.
2. Change the Printer Main Board.
Change the TPH.
1. Change the CTRL Board.
2. Change the Kiosk Main Board.
3. Change the LCD Touch Panel.
Check Item
