How to Connect Logic Analyzer
DS1000D Series Oscilloscopes provide the Logic Analyzer to meet
users' requirement.
1. Before connect the logic analyzer, please turn off the power
source to avoid any possible damage during the connection.
2. Connect the Logic cable to the digital input port on the front
panel of the oscilloscope as shown in the above figure. There is
a sign on the Logic Probe that you can only connect the cable in
the proper direction.
Quick Guide for DS1000E, DS1000D Series
Connect Logic Analyzer
