Appendix A

Specifications

Input frequency
HRC/IRC frequency
assignments
Number of channels:
Average digital input level:
64 QAM
256 QAM
Data carrier:
Frequency
Bandwidth
Level
Video signal to noise ratio
Remod output frequency
accuracy
Return loss:
Input
Output
Spurious output
Remod output level
Isolation (input/output)
On-screen display (OSD):
Screen size
Message/barker capacity
Operating environment range:
Temperature
Humidity
AC voltage:
USA and Canada
Mexico
Power dissipation
Surge protection
Size
Weight
88.75 to 858 MHz (excluding data carrier frequency)
Downloadable
128 carriers per cable; more than one digital channel per carrier,
content dependent
–15 dBmV to +15 dBmV
–12 dBmV to +15 dBmV
QPSK-modulated carrier
Agile
1.5 MHz
–15 dBmV to +15 dBmV
57 dB minimum for baseband output, unified weighted, 4.2 MHz
bandwidth
±80 kHz
4 dB minimum
8 dB minimum
–57 dBc maximum, in band
10 to 15 dBmV
70 dB minimum
352 x 480 pixels (configuration dependent)
Up to 40 pages (configuration dependent)
0° to 40°C (32° to 104°F)
5 to 95% (non-condensing)
105 to 125 V, 60 Hz
114 to 140 V, 60 Hz
16 W at 115 V
Provided on power supply and RF ports
5.5 x 6.7 x 1.8 inches
0.85 pounds
