EXFO's Next-Generation MaxTester: Much More
Features, Much Bigger Performance
The new FOT-930 MaxTester Multifunction Loss Tester is designed to help network service providers address CAPEX and OPEX issues, enable installers
to easily adapt to all network types, and provide CATV operators with a single-unit solution to their backreflection, fiber-length, high-power and bidirectional
loss measurement needs. Combined with its video fiber inspection probe, this unit also enables the easy detection of dirty or damaged connectors,
providing a clear view of connectors and fiber ends on the FOT-930's high-resolution display.
All-in-one unit: combines up to eight instruments
Loss meter
Power meter
Optical return loss (ORL) meter
Visual fault locator
Multimode and singlemode light sources
Digital talk set
Fiber length tester
Video fiber inspection probe
FasTesT function*: one-touch,
automated measurements in 10 seconds
Bidirectional loss and ORL testing at up to
three singlemode wavelengths
Bidirectional loss testing at two multimode
wavelengths
Fiber length measurement
Flexible solution: five-wavelength multimode
and singlemode configurations meeting the
requirements of installers/contractors for all
test situations
Up to three singlemode wavelengths—
1310, 1550 and a choice between 1490
and 1625 nm—on one port
Two multimode wavelengths—850 and
1300 nm—on a second port
*Protected by US patent(s) 5,305,078 and/or 5,455,672.
With countless configurations available, the
FOT-930 MaxTester is the handheld unit of
choice for today's network service providers,
fiber-optic network installers/contractors and
CATV operators.
FOT-930 MaxTester
Future-proof: next-generation features meeting
the latest industry requirements
User-configurable pass/fail thresholds that can
be adjusted to different industry standards
FTTx ready, allowing for the testing of
passive optical networks (PONs) at 1310,
1490 and 1550 nm, the three ITU-T
G.983.3 recommended wavelengths
for PONs
Cost of ownership: lowest on the market
Three-year warranty and recommended
calibration interval
Error-free testing achieved through visual
loss and ORL pass/fail analysis
Minimized training time, thanks to a single
user interface for the eight instruments
included in this all-in-one unit
Easy to use and ergonomic: built for today's
fiber-optic test requirements
Handy, eye-catching and rugged handheld
package
High-resolution color display
Complete data management and report
generation
Nine hours power autonomy provided by
field-swappable rechargeable batteries
