Partlow MRC 7000 Installation & Operation Manual page 4

4
FIGURES & TABLES
Figure 1-1 Recorder Description
Figure 1-2 Recorder Display
Figure 2-1 Installation Panel Dimensions Conduit Opening Locations
Figure 2-2 Noise Suppression
Figure 2-3 Noise Suppression
Figure 2-4 Board and Terminal Locations
Figure 2-5 AC Power Input
Figure 2-6 Thermocouple Inputs
Figure 2-7 RTD Inputs
Figure 2-8 Milliamp, Volt and Millivolt Inputs
Figure 2-9 Digital Communications
Figure 2-10A SPST Relay Output
Figure 2-10B SPDT Relay Output
Figure 2-11 SSR Output
Figure 2-12 Current Output
Figure 2-13 24 VDC Power Supply Option
Figure 3-1 Keypad Features
Figure 4-1 Changing Pens
Table 3-1 Enable Mode Configuration Procedure
Table 3-2 Program Mode Configuration Procedure
Table 3-3 Alarm Set Mode Configuration Procedure
Table 4-1 Calibration Procedure
Table 4-2 Test Procedures and Description
FLOW CHARTS
Flow - Alarm Set
Flow - Calibration
Flow - Enable
Flow - Program
Flow - Test
5
6
8
10
10
13
14
14
14
15
15
16
16
16
17
17
19
33
24
28
32
35
40
32
34
24
25
39
