Appendix C - Order Matrix
7
PEN 1
1 Recorder Only
4 High/Low Limit
PEN 2
0 None
1 Recorder only
*RELAY OUTPUTS
0 None
1 One SPST
2 Two SPST
4 Four SPST
6 Six SPST
7 One SPDT
8 Two SPDT
9 Two SPDT and Two SPST
*SSR DRIVER OUTPUTS
0 None
1 One
2 Two
4 Four
6 Six
8 Eight
4 TO 20MA OUTPUTS
0 None
1 One Standard
2 Two Standard
3 Three Standard
4 Four Standard
* Total quantity of SPST Relays and SSR Drivers must be less than or equal to (8) eight. When SPDT
relays are included, the total must be less than or equal to six.
** This option comes with a structural foam cover.
† N3 - NEMA3 Equivalent Spray Resistant Enclosure (provided with the instrument).
0 0
OPTION SUFFIX
Blank None
N3 NEMA 3 †
AW RTD Depression on Pen 2
AD 0/100 mVDC Input
AE N3 plus AW
VOLTAGE
1 115VAC Input
2 115/230 VAC Input
CSA Approved
4 115VAC Input
5 115/230VAC Input
ENCLOSURE OPTIONS
2 Std Cover (Plastic Window)
4 Door Lock**
6 Sealed Conduit Connectors
7 Combination of 4 & 6**
COMMUNICATIONS
0 None
2 RS-485 Total Access
FIXED CHARACTER
FIXED CHARACTER
TRANSMITTER POWER SUPPLY
0 None
1 24VDC Regulated/Isolated
