Appendix D - Specifications
Measurement Error Limit
Ambient Temperature Error
Scan Rate
Display Decimal Positions
Noise Rejection
Line Voltage
Power Consumption
Operating Temperature
Storage Temperature
Humidity
Dimensions
Weight
Sensor Fault Detection
Agency Approvals
Transmitter Power Supply
Warranty
• Type J, K, T, E, N, C T/C's and RTD +/- 0.25% of
reading plus 1 degree @ 25 degrees C
• Type R, S, B T/C's +/- 0.25% of span @ 25 degrees C
• mA, mV, and VDC +/- 0.25% of scaled span plus 1
Whole Digit @ 25 degrees C
0.01% of span per degree C deviation from 25 derees C
1 scan/second
One, two or three decimal places (0.1 or 1 degree for
T/C or RTD)
Normal mode, 85dB minimum at 60Hz or greater.
Common mode, 90dB minimum, 115VAC maximum.
115/230VAC +/- 1-% 50/60 Hz
25VA maximum
32 degrees to 131 degrees F
0 degrees to 55 degrees C (ambient)
-40 degrees to 149 degrees F
-40 degrees to 65 degrees C
0 to 90% RH, noncondensing
13.19 H x 15.13 W x 3.63 Deep
20 pounds maximum
Displays SnSr for sensor or transmitter break. Alarms go
off. Relays are de-energized. Fault detection is not
functional for 0-5V or 0-20 mA inputs.
UL Spec. 1092 File#E67237
CSA Spec. C22-2 File#LR39885
Provides up to 40mA of current at 24 VDC
3 years, see back page for details
