Directed Electronics DB3 Installation Manual page 11

Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
12 Volts
Brake Wire
Trunk/Hatch Release
11
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input
No Connection
No Connection
No Connection
No Connection
No Connection
(+) W2W Only - Ignition Input
(-) W2W Only - Ground When Running (Status) Input
Color
Green
Black
Blue
Red
Color
N/A
N/A
Connects To
Wire Location
VESCM above driver kick, white 73 pin plug, pin 1
VESCM above driver kick, white 73 pin plug, pin 58
VESCM above driver kick, black 73 pin plug, pin 32
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
No Connection
No Connection
No Connection
Remote Starter
Remote Starter
Description
Description
No Connection
No Connection
(+/-) Wire Color
+ Red/White (40A)
+ Black/Red
- White (rear handle switch)
(+/-) Wire Color
403.VW06 1.41 2017 Volkswagen Golf GTI (Smart Key)
© 2017-10-25 Directed. All rights reserved.
