Vehicle connections

The connection information listed below is specific to the 2017 Volkswagen Golf GTI (Smart Key). Refer to "Pre-installation and application warnings" for a list of important
notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
10
Description
No Connection
No Connection
(DATA) HS CAN High
(DATA) HS CAN Low
(DATA) HS CAN High
(DATA) HS CAN Low
Relay N.O. Pk Light Output
Relay COM Parking Lights Interrupt
Relay N.C. Parking Lights Interrupt
Relay N.C. Key Wrap
Relay COM Key Wrap
Relay N.O. Key Wrap
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
(-) Hazard Light Output
(-) PTS
(-) W2W Only - Door Output
(-) W2W Only - Trunk Output
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
(+) W2W Only - Ignition Output
No Connection
(MUX) PTS
No Connection
No Connection
(-) W2W Only - Hood Output
Connects To
Wire Location
No Connection
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 6
OBD-Data Link Connector, black 16 pin plug, pin 14
Electronic Steering Column Lock Module, black 16 pin plug,
pin 16
Electronic Steering Column Lock Module, black 16 pin plug,
pin 15
Headlight Switch, red 10 pin plug, pin 3
Headlight Switch, red 10 pin plug, pin 8
Headlight Switch, red 10 pin plug, pin 8
Immobilizer Reader Coil in steering column, 2 pin plug, pin 1
Immobilizer Reader Coil in steering column, 2 pin plug, pin 1
Immobilizer Reader Coil in steering column, 2 pin plug, pin 1
VESCM above driver kick, white 73 pin plug, pin 1
Connects To
Wire Location
Not Applicable
Electronic Steering Column Lock Module, black 16 pin plug,
pin 13
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
Electronic Steering Column Lock Module, black 16 pin plug,
pin 4
No Connection
No Connection
Remote Starter
(+/-) Wire Color
Data Orange/Red
Data Orange/Brown
Data Orange/Green
Data Orange/Brown
+ Gray/Yellow
Cut Red/White
Cut Red/White
RF Blue
RF Blue
RF Blue
+ Red/White (40A)
(chassis ground)
(+/-) Wire Color
- Violet
- Violet/Blue
403.VW06 1.41 2017 Volkswagen Golf GTI (Smart Key)
© 2017-10-25 Directed. All rights reserved.
