- Page 1 Models 7652V, 7652P, 7652X Security and Remote Start Owner’s Guide © 2008 Directed Electronics, Vista, CA G5902V 2008-03...
- Page 3 Contents Government regulations .......................5 Warning! safety first ........................7 What is included ..........................9 Important information ........................9 Your warranty........................9 Replacement remotes.......................10 Caution ..........................10 Responder LC 2-Way ........................11 Responder LC 1-way ........................12 Transmitter configuration ....................13 System maintenance ...
- Page 4 Rapid resume logic .........................40 Power saver mode........................41 System..........................41 2-way remote ........................41 Programming options ......................42 Security & convenience expansions ..................44 Glossary of terms ........................46 Quick reference guide ......................49 Limited lifetime consumer warranty ..................51...
-
Page 5: Government Regulations
This device complies with the Industry Canada Radio Standards Specification © 2008 Directed Electronics. All rights reserved. - Page 6 Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this device. © 2008 Directed Electronics. All rights reserved.
-
Page 7: Warning! Safety First
Leave the vehicle in neutral and be sure no one is standing in front or behind the vehicle. • Only remote start on a flat surface • Have the parking brake fully engaged © 2008 Directed Electronics. All rights reserved. - Page 8 CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AUTHORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS. © 2008 Directed Electronics. All rights reserved.
-
Page 9: What Is Included
10 days of purchase. Your product warranty will not be validat- ed if your warranty registration is not returned. Make sure you receive the warranty registration from your dealer. It is also necessary to keep © 2008 Directed Electronics. All rights reserved. -
Page 10: Replacement Remotes
➤ Caution This product is designed for fuel injected vehicles only. Use of this product in a standard transmission vehicle must be in strict accordance with this guide. © 2008 Directed Electronics. All rights reserved. -
Page 11: Responder Lc 2-Way
Label Back of remote has label to identify the remote as 2-way or 1-way. Battery Door For accessing batteries when necessary. to exit. Note: If Keypad Lock is On, press and then press © 2008 Directed Electronics. All rights reserved. -
Page 12: Responder Lc 1-Way
Back of remote has label to identify the remote as 2-way or 1-way Battery Door Remove to access batteries when neces- sary. For more details, see p.10 to exit. Note: If Keypad Lock is On, press and then press © 2008 Directed Electronics. All rights reserved. -
Page 13: Transmitter Configuration
Press one time to Arm Feedback: Unlock icon appears and remote beeps twice arm Notes: Command: Press one time to activate Remote Start Feedback: Remote Start Icon appears on screen. remote emits a tone Remote Notes: Start © 2008 Directed Electronics. All rights reserved. - Page 14 Feedback: Function mand received. Shift Notes: Each Press then release, shifts the function of the command button. Pressing more than one button simultaneously generates an Error tone and the F-Shift LED turns ON. © 2008 Directed Electronics. All rights reserved.
- Page 15 Cabin temperature Press one time, then Hold for 1.5 seconds. Command: Screen will display current in cabin temperatue. Feedback: Cabin temperature is displayed on the remote. LED lights Notes: up to indicate a range. © 2008 Directed Electronics. All rights reserved.
- Page 16 Enables or disables the remote start timer mode. Notes: Aux 2 Press two times and then press Command: Text will display the item activated Feedback: This is an optional feature. See your sales rep/installer Notes: for details. © 2008 Directed Electronics. All rights reserved.
- Page 17 Enables or disables the SmartStart feature. Notes: Aux 3 Press three times and then press Command: Text will display the item activated Feedback: This is an optional feature. See your sales rep/installer Notes: for details. © 2008 Directed Electronics. All rights reserved.
- Page 18 Press four- times and then hold for 1.5 seconds. Command: Text scrolls last trigger. Feedback: Trigger refers to the remote tones and LED pattern gener- Notes: ated by the last alarm trigger event. © 2008 Directed Electronics. All rights reserved.
-
Page 19: System Maintenance
When charging is complete the LCD then displays “ FULL” . Note: If the battery has been severely discharged all remote functions are disabled for a short charge period. The battery status outline flashes © 2008 Directed Electronics. All rights reserved. -
Page 20: Low Battery Indicator
and CHARGE is displayed on the LCD. Once the battery has accu- mulated enough charge for functionality, the LCD icons initialize with a beep sound, the battery status outline stops flashing and the remote becomes operational while still displaying CHARGE. The temperature range over which Warning! the battery can be charged is 0ºC TO 45ºC... -
Page 21: Lcd Iayout
ALL ALL Locked Hood (Tr ger) disarmed Hood (Zone bypass) Unlocked Trunk (Trigger) Alarm Trunk (Zone bypass) Home (Garage - Open) Remote Start Home (Garage Close) Battery Status Pager On Small Remote Start © 2008 Directed Electronics. All rights reserved. -
Page 22: Multi-Car Control Capability
Sensor Bypassed Arrow All Zones Sound Wave Large Siren Car Door ➤ Multi-car control capability You can operate the 2-way remote control system for two cars, with full command capability for both vehicles. © 2008 Directed Electronics. All rights reserved. -
Page 23: Using The System
If the power door locks have been connected, the doors will lock. The system will automatically check for errors when it arms. The 2-way remote will “ chirp” once and blink the LOCK indicator to © 2008 Directed Electronics. All rights reserved. -
Page 24: While The System Is Armed
➤ While the system is armed • Fail-Safe Starter Kill The starter is disabled by the system’s Fail-Safe starter kill. Alarm Responses The security system can generate two levels of alarm: Warn Away - Soft © 2008 Directed Electronics. All rights reserved. - Page 25 Full Alarm response is triggered by: • Heavier impact to the vehicle (detected by the Stinger Double- Guard shock sensor). • Opening the trunk or hood. • Opening a door: the Progressive Door Trigger feature will first © 2008 Directed Electronics. All rights reserved.
-
Page 26: Modified Arming Modes
LED flashes and the remote sounds an error tone. Now, slight impacts or vibrations will not trigger Warn-Away. Heavy impacts will still trigger Full Alarm. Note: The next time you arm the system, Warn-Away will work normally. © 2008 Directed Electronics. All rights reserved. - Page 27 2- way remote to be paged. All entry points (doors, hood, etc.) will still trigger the siren. Press the button three times, and then press the button. Note: The next time you arm the system, it will function normally. © 2008 Directed Electronics. All rights reserved.
-
Page 28: Disarming The System
High-Security Disarming If you want the Full Alarm response to stop without unlocking the doors, press the button. The system will re-arm and the current alarm re- sponse will reset. ➤ System override © 2008 Directed Electronics. All rights reserved. - Page 29 If the Override Switch has been programmed to a new number of presses by your authorized dealer, that number should be indicated below. Override Switch Number ___________ © 2008 Directed Electronics. All rights reserved.
-
Page 30: Using The Remote Start
If the hood is open or is the brake pedal is pressed, the vehicle will not start using remote start. The remote starter shuts down: • When the brake pedal is pressed • The hood is opened © 2008 Directed Electronics. All rights reserved. -
Page 31: Runtime Check
Exit the vehicle and close the door. Arm the alarm (the vehicle should shut off when arming the sys- tem). You can now remote start the vehicle. If a door is opened or if the alarm © 2008 Directed Electronics. All rights reserved. -
Page 32: Timer Mode
Turbo timer mode keeps the engine running after arriving at your desti- nation for a programmable period of 1, 3, 5 or 10 minutes. This allows the system’s timer to conveniently cool down the turbo after you have © 2008 Directed Electronics. All rights reserved. - Page 33 This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of time, but would like to leave the motor running and the climate controls on. © 2008 Directed Electronics. All rights reserved.
- Page 34 After you exit the vehicle you can arm the alarm and the car will remain running. If the vehicle shuts down when arming, then the unit did not enter the valet take-over mode. © 2008 Directed Electronics. All rights reserved.
-
Page 35: Safety Features
To disable the remote start, move the shutdown toggle switch to the OFF position. Check with your installer for the location. Location of Shutdown Switch____________________________ © 2008 Directed Electronics. All rights reserved. -
Page 36: Diagnostics
Once the light turns off, however, the security system resumes normal monitoring. Note: Bypass Notification does not occur when the system is in Silent Mode or if the notification chirps have been programmed off by the installer. © 2008 Directed Electronics. All rights reserved. -
Page 37: Disarming
Action Number of Chirps Description System armed 1 (3-second delay) System armed with bypass notification Disarm System armed Disarm System disarmed with Tamper Alert Disarm System disarmed © 2008 Directed Electronics. All rights reserved. -
Page 38: Table Of Zones
For example: If zone 3 was active or triggered, the LED will blink three times with a two-second pause. Then it will blink three times again, and repeat until the ignition is turned on. © 2008 Directed Electronics. All rights reserved. -
Page 39: Nuisance Prevention® Circuitry
The vehicle doors are protected by NPC differently. If your security system is triggered by an open door for three full cycles, the system will bypass the doors until the trigger ceases. © 2008 Directed Electronics. All rights reserved. -
Page 40: Owner Recognition
Valet Mode. This applies to all states of the system including arm, disarm, and Valet Mode. © 2008 Directed Electronics. All rights reserved. -
Page 41: Power Saver Mode
Pressing any button on the remote will restore the paging function. The default setting is ON. See Remote control programming section of this guide or ask your dealer for details on how to program. © 2008 Directed Electronics. All rights reserved. -
Page 42: Programming Options
OFF. (Some states have laws against sirens sounding in moving cars.) • Full trigger response 30 or 60 seconds: This determines how long the full triggered sequence lasts. Some states have laws regulating © 2008 Directed Electronics. All rights reserved. - Page 43 The chirps can be either full volume or 6 decibels quieter than the full alarm blast. • Comfort closure is a programming option which closes the ve- hicle’s windows after remote locking. © 2008 Directed Electronics. All rights reserved.
-
Page 44: Security & Convenience Expansions
Power Trunk Release: The accessory output of the system can operate a factory power release for the vehicle’s trunk or hatch. Although the © 2008 Directed Electronics. All rights reserved. - Page 45 Ultrasonic Cabin Sensor: Using the 509U Ultrasonic cabin sensor pro- vides a field of protection inside the car to protect your belongings. © 2008 Directed Electronics. All rights reserved.
-
Page 46: Glossary Of Terms
In-vehicle status LED: A light used to indicate the status of your system. It is located on your systems control center. Shock Sensor: This system has a dual zone shock sensor. This sensor is mounted in the vehicle and designed to pick up impacts © 2008 Directed Electronics. All rights reserved. - Page 47 Zone: A zone is a separate input that the alarm can recognize as unique. Each input to the system is connected to a particular zone. Often, two or more inputs may share the same zone. © 2008 Directed Electronics. All rights reserved.
- Page 48 © 2008 Directed Electronics. All rights reserved.
-
Page 49: Quick Reference Guide
Quick reference guide Arming To arm, press . When the system arms, the LOCK LED blinks for one second, with 1 beep and siren tone. Arming while driving To arm the system while driving, press on your remote while the vehicle is running. - Page 50 © 2008 Directed Electronics. All rights reserved.
- Page 51 Then wait a few seconds. Turn the ignition key to the OFF position. The engine will remain running until the programmed time elapses or a shut- down input is received. Location of Valet button_________________________________ © 2008 Directed Electronics. All rights reserved.
-
Page 52: Limited Lifetime Consumer Warranty
Limited lifetime consumer warranty Directed Electronics. (“ Directed” ) promises to the original purchaser to repair or replace (at Directed’s election) with a comparable reconditioned model any Directed unit (hereafter the “ unit” ), excluding without limitation the siren, the remote transmitters, the associated... - Page 53 Authorized dealer’s company name and address Type of alarm installed Year, make, model and color of the automobile Automobile license number Vehicle identification number All security options installed on automobile Installation receipts 920-0003 06-06 © 2008 Directed Electronics. All rights reserved.
- Page 54 © 2008 Directed Electronics. All rights reserved.
- Page 55 The company behind this system is Directed Electronics Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology.
