Summary of the Calculations - 2 x 2 Display Wall

Region 1
Top 0
Left 0
Region 2
Top 0
Left A to B - Y to B ÷ A to B x 1920 =
Region 3
Top A to C - H to C ÷ A to C x 1080 =
Left 0
Region 4
Top B to D - Q to D ÷ B to D x 1080 =
Left C to D - M to D ÷ C to D x 1920 =
A
1
G
H
3
C
Width A to X ÷ A to B x 1920 =
Height A to G ÷ A to C x 1080 =
Width Y to B ÷ A to B x 1920 =
Height B to K ÷ A to C x 1080 =
Width C to L ÷ A to B x 1920 =
Height H to C ÷ A to C x 1080 =
Width M to D ÷ A to B x 1920 =
Height Q to D ÷ A to C x 1080 =
X Y
2
I J
N P
4
L M
Fig.1
8
B
K
Q
D
