4. Reconnect LAN3 to the network.
5. Disconnect LAN2 from the network. LAN2 becomes backup and LAN3 becomes active.
6. PING the IP Address of the bonded ports. The PING statistics should show 0% lost. This
confirms that LAN3 is active.
7. Reconnect LAN3 to the network and perform the steps in Restoring Redundant Eth-
ernet Ports (on page 175).
If the PING statistics don't show 0% lost, there is a problem with connectivity to, or con-
figuration of, LAN2 and/or LAN3.
IMPORTANT: After verifying redundancy, perform the steps in Restoring Redundant Eth-
ernet Ports (on page 175).
Note: The NETWORK - Ethernet page and LAN2 Configuration window do not indicate which
port is currently active. The LAN2 Configuration page only shows the initial configuration for
Redundancy.

RestoringRedundantEthernetPorts

1. On the NETWORK - Ethernet page, click the EDIT button for LAN2.
2. For Redundant, select Backup.
3. Click the APPLY button and then click the APPLY button on the NETWORK - Ethernet page.
4. Click the EDIT button for LAN2.
5. For Redundant, select Active.
6. Click the APPLY button and then click the APPLY button on the NETWORK - Ethernet page.

Managing Users

Use the ADMIN - Users page to add, delete, and edit user profiles, including passwords and
password recovery. All users have full administrative privileges.

ChangingthePassword

1. Enter current user's Old Password.
2. Enter the New Password and Retype New Password.
3. (Optional) Configure password recovery for the current user as described in Enabling
Password Recovery (on page 175).
4. Click the APPLY button.
See also: Properties of User Names and Passwords (on page 23)

EnablingPasswordRecovery

1. For new and current users, select the Password Recovery checkbox.
