1) Set HW Clock to Freerun?
1) OK (i.e., Apply the entered time to the
Hardware Clock and don't use references)
2) Cancel
2) Brightness (Adjust the brightness of the front panel
display)
1) Low (Extends display life)
2) Medium
3) High
3) 12/24 (Appears if the TIMING - Time Zone page is set
to a non-UTC Time Zone. Select a 12 or 24-hour clock
format)
1) 12 (AM/PM)
2) 24 Hour
3) Sys Control (System Control)
1) Keypad
1) Set Password (Sets the password the Lockout
function. The *first time* the interface asks for
the "Current Password", enter 123. No
password recover or reset feature is available for
the keypad, except to reset factory defaults using
the ADMIN - Factory Reset page.)
2) Lockout (Password protects the keypad from changes.
Asks for confirmation.)
2) Shutdown (Halts the SyncServer. Press the ENTER button
to confirm. Notifies the user when "System Stopped. OK
to Turn Power Off Now!")
4) USB (Backs up or restores the configuration to/from a USB
flash drive)
1) Backup Cfg (Backs up the current configuration of the
SyncServer to the USB drive.)
2) Restore Cfg (Applies the SyncServer configuration on
the USB drive to the SyncServer.)
3) Upgrade Software (Applies the software upgrade file on
the USB drive to the SyncServer.)
Notes:
Using 1) LAN1, 1) Config clears all other network port settings.
The factory default password for the keypad is '123'.
997-01520-02 Rev.
F1..........................................................................
MENU Button
Page 105
