Rear Panel
Index Bit
countname
----- -----
70 (bit = 0)
71 (bit = 0)
72 (bit = 0)
73 unlock (1 = unit is not locked to a reference)
74 (bit = 0)
75 tq1(1 = timing error estimate > 1us)
76 tq2 (1 = timing error estimate > 10us)
77 tq3 (1 = timing error estimate > 100us)
78 tq4 (1 = timing error estimate > 1ms)
For Legacy TrueTime IRIG B, the following CF bits are encoded:
Index Bit
countname
----- -----
50 (bit = 0)
51 (bit = 0)
52 (bit = 0)
53 unlock (1 = unit is not locked to a reference)
54 (bit = 0)
55 tq1(1 = timing error estimate > 1us)
56 tq2 (1 = timing error estimate > 10us)
57 tq3 (1 = timing error estimate > 100us)
58 tq4 (1 = timing error estimate > 1ms)
When Legacy TrueTime IRIG B input is selected, the SyncServer will not lock to the incoming
code if the unlock bit = 1.

GPSReceiver

Note that the SyncServer model 350i does not have a GPS receiver.
