STATUS Button
NTP Packet I/O: The number of NTP packets the SyncServer has replied to and initiated. The
SyncServer replies to clients that send NTP requests. The SyncServer also sends NTP
requests when the NTP daemon isn't synchronized (i.e., Sync LED is RED) and when it is
configured to synchronize to an NTP association (e.g., a Server type association).
Also see STATUS - NTP (on page 28).
Alarm Status Screen
Current alarm status.
Current: The total number of active alarms. Use the left/right arrows for search through the
list of alarms.
Major: List of current major alarms
Minor: List of current minor alarms
Also see ADMIN - Alarms (on page 85).
LAN Status Screens
Multiple screens, one for each network port.
State: Shows "Up" if the port is enabled and "Down" if the port is disabled.
IPv4 Addr: Shows the address of the port.
SM: Shows the subnet mask (IPv4) or scope (IPv6).
GW: Gateway address.
IPv6 Addr: The IPv6 Link local address for this port.
Also see NETWORK - Ethernet (on page 32).
Hardware Clock Status Screen
Hardware Clock and Input Reference status.
Source: (2 fields) The first field is the name of the current reference. The second field indic-
ates "Locked" when the Hardware Clock is synchronized to that reference.
HH:MM:SS H/W: The UTC or GPS time from the Hardware Clock, depending on the
"Ignore..." setting on the TIMING - HW Clock page.
GPS In: Indicates "Locked" if the GPS receiver is a valid source of time.
1PPS In: Indicates "Locked" if 1PPS In is a valid source of phase.
Timecode In: Indicates "Locked" if IRIG In connector has a valid source of time.
10MHz In: Indicates "Locked" if 10MHz In is a valid source of frequency.
Also see TIMING - HW Clock (on page 61).
GPS Receiver Status Screen
GPS receiver status.
Status: Indicates "Locked" when the receiver has a valid timing solution.
