Extreme USB USB 1.1 RV1850 Quick Start Manual

USB 1.1 RV1850
1-port USB 1.1 85m* Cat 5e Extender System
Quick
Start
Guide
Before you get started, ensure that all the drivers
required for your USB device(s) are installed.
1 Place units where desired, and connect the Cat 5e
(solid core) extension link cable to the Link ports
(RJ45) on the local extender and remote extender.
Local Extender
(Cat 5e cable not included)

Up to 85m*

2

Connect the local extender to the computer.

Computer
3

Attach the USB device to the remote extender.

* Up to 40m for all USB devices; 85m achievable for most
low-powered HID USB devices.
Remote Extender
#90-01244-A01
