This user's guide describes the operation of the TSC2117EVM-K evaluation module (EVM). The EVM
features a TSC2117 touch screen controller with stereo audio codec, amplifiers for speakers and
headphones and a digital signal processing module. Together with the USB-MODEVM board, the
TSC2117 Control Software and a PC running Windows™ XP it is a plug-and-play solution to evaluate the
capabilities of the TSC2117.
The information in a caution or a warning is provided for your protection. Read each caution and warning
carefully.
1
1.1
1.2
1.3
....................................................................................................................
2
2.1
2.2
2.3
2.4
2.5
2.6
3
3.1
3.2
3.3
1
2
Main Window
3
4
5
6
7
8
9
10
11
12
13
I2S, I2C are trademarks of Koninklijke Philips Electronics N.V.
Windows is a trademark of Microsoft Corporation.
SPI is a trademark of Motorola, Inc.
SLAU282 - April 2009
Submit Documentation Feedback
...............................................................................................................
..........................................................................................................
........................................................................................................
....................................................................................................
....................................................................................................
...........................................................................................................
.............................................................................................................
........................................................................................................
........................................................................................
.............................................................................................................
.........................................................................................
..................................................................................................
..............................................................................................
......................................................................................
................................................................................
.........................................................................................
..........................................................................................
.................................................................................................................
...........................................................................................................
............................................................................................................
...........................................................................................................
.........................................................................................
...............................................................................
.................................................................................................
..............................................................................................................
..............................................................................................
.............................................................................................................
....................................................................................................
...............................................................................
..............................................................
List of Figures
User's Guide
SLAU282 - April 2009
TSC2117EVM-K
TSC2117EVM-K
2
2
2
2
3
3
4
4
4
5
6
19
19
22
23
25
26
28
3
5
7
8
9
11
12
13
14
15
16
17
18
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments TSC2117EVM-K
Summary of Contents for Texas Instruments TSC2117EVM-K
-
Page 1: Table Of Contents
SLAU282 – April 2009 TSC2117EVM-K This user’s guide describes the operation of the TSC2117EVM-K evaluation module (EVM). The EVM features a TSC2117 touch screen controller with stereo audio codec, amplifiers for speakers and headphones and a digital signal processing module. Together with the USB-MODEVM board, the TSC2117 Control Software and a PC running Windows™... -
Page 2: Contents 1 Evm Overview
EVM Overview Introduction The TSC2117EVM-K features a TSC2117 touch screen controller with stereo audio codec, amplifiers for speakers and headphones and a digital signal processing module. Together with the USB-MODEVM board, the TSC2117 Control Software and a PC running Windows XP, it is a plug-and-play solution to evaluate the capabilities of the TSC2117. -
Page 3: Evm + Pc
• Connect a line-level audio source to J1 (3,5 mm jack) 2.1.2 Touch Screen Connections The TSC2117 EVM is compatible with 4-wire resistive touch screens. Connect the touch screen to J4 (X+, X–, Y+, Y–). SLAU282 – April 2009 TSC2117EVM-K Submit Documentation Feedback... -
Page 4: Control Software
The control software will automatically detect a TSC2117EVM-K once it is connected to a USB port of the If no TSC2117EVM-K is connected to the PC, the control software changes to a simulation mode, where it is possible to retrieve script commands based on user input within the block diagram. -
Page 5: Main Window
At the bottom of the main window is a status bar that provides information about the state of the communication between the control software and the TSC2117EVM-K. It also shows hints about elements in the block diagram, for example the I2C page and register / bit location of a selected switch. -
Page 6: Dialogs And Active Objects
Most dialogs are linked to active objects and are opened by clicking on the active object. A few dialogs are not linked to active objects and are opened using the View menu. TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback... -
Page 7: Initialization Script
Each use case owns a unique initialization script which will automatically run when a TSC2117EVM-K is detected or if the user selects another use case. To show or edit the initialization script, choose View->Init Script… from the main window menu bar. -
Page 8: Command Dialog
Class-A/B HP Driver amplifier (note that the Record checkbox is checked). A single command to read four bytes starting at address 0x28 was executed and the result is displayed in the Read Data field. TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback... -
Page 9: Register Inspector
Figure 5. Register Inspector The register inspector displays the content of the TSC2117 registers. The control software will read all TSC2117 registers when a TSC2117EVM-K is detected. To force reading the content of one page, click the Refresh button. • The Page edit field selects the page to be displayed. - Page 10 The coordinate system will shift accordingly to reflect the resulting attenuation. • To avoid clipping, add additional attenuation with the Attenuate slider. • To retrieve the biquad coefficients, open the command dialog (see 0) and check Record. TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback...
-
Page 11: Clock And Digital Signal Routing
• Click on the “Back To Codec” active object to return to the previous block diagram. • Click on the “Internal Clock Gen Module” active object to display the digital configuration dialog. SLAU282 – April 2009 TSC2117EVM-K Submit Documentation Feedback... -
Page 12: Digital Configuration: Codec Clock / Pll
5. The Results list shows all clock settings that fulfill the chosen parameters. Double click on one of the results to program the TSC2117 with the new settings. Each result has the following columns: TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback... -
Page 13: Advanced Clock Settings
It is possible to put out a clock signal CLKOUT. Select the clock source, the divider and the destination pin using the advanced clock settings dialog. SLAU282 – April 2009 TSC2117EVM-K Submit Documentation Feedback... -
Page 14: Audio Interface
The Word Length drop down box defines the number of bits per audio word. The DIN/DOUT offset defines where the data for the ADC or from the DAC is located in the bit-stream. This is required for TDM (DSP) interface format. TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback... -
Page 15: Touch Screen Active Object
To change the touch screen module parameters, click on the touch screen active object. This will display the touch screen dialog. To clear the touch screen drawing, open the touch screen dialog and click on the Clear button. SLAU282 – April 2009 TSC2117EVM-K Submit Documentation Feedback... -
Page 16: Sar Adc Data
The inside of the SAR data active object (rectangle) shows the conversion results for IN1, IN2, BAT and TEMP. Figure 11. SAR ADC Data To change the SAR ADC module parameters, click on the SAR data active object. This will display the SAR ADC dialog. TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback... -
Page 17: Automatic Gain Control
• The AGC Gain field shows the applied gain (if the AGC is enabled) and allows setting a maximum gain using the slider. Advanced AGC controls are available by clicking the More button. This will reveal further controls to adjust various AGC parameters. SLAU282 – April 2009 TSC2117EVM-K Submit Documentation Feedback... -
Page 18: Drc Transfer Function And Drc Dialog
The DRC transfer function will change depending on the digital volume setting and the DRC threshold. Click on the DRC transfer function to reveal the DRC dialog, which contains a slider to change the DRC threshold. TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback... -
Page 19: Evm Hardware
SPLN (speaker) SPLP (speaker) SPRN (speaker) SPRP (speaker) BATT Headphones Headphones (filtered) AGND Table 2. Touch Screen Connector Function Y– X– Y– Y– X– Y– Table 3. GPI Connector Function GPI1 GPI2 GPI3 SLAU282 – April 2009 TSC2117EVM-K Submit Documentation Feedback... -
Page 20: Jumpers
SPI MOSI Slave Serial Data Input P12.12/J12.12 P12.13/J12.13 MISO SPI MISO Slave Serial Data Output P12.14/J12.14 RESET TAS1020B Reset P12.15/J12.15 P12.16/J12.16 I2C Serial Clock P12.17/J12.17 P12.18/J12.18 DGND Digital Ground P12.19/J12.19 P12.20/J12.20 I2C Serial Data Input/Output TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback... -
Page 21: Expansion Connectors
Master Clock Input P22.18/J22.18 DGND Digital Ground P22.19/J22.19 P22.20/J22.20 Table 7. Power Supply Pin Number Signal P23.1/J23.1 P23.2/J23.2 P23.3/J23.3 +5VA P23.4/J23.4 P23.5/J23.5 DGND P23.6/J23.6 AGND P23.7/J23.7 +1.8VD P23.8/J23.8 P23.9/J23.9 +3.3VD P23.10/J23.10 +5VD SLAU282 – April 2009 TSC2117EVM-K Submit Documentation Feedback... -
Page 22: Evm Schematics
EVM Hardware www.ti.com EVM Schematics The schematic diagram for the TSC2117EVM is provided as a reference. TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback... -
Page 23: Evm Bill Of Materials
REVISION HISTORY ENGINEERING CHANGE NUMBER APPROVED TSC2117_RGZ Daughtercard_Interface TSC2117_RGZ.Sch Daughtercard_Interface.Sch DATA ACQUISITION PRODUCTS HIGH-PERFORMANCE ANALOG DIVISION SEMICONDUCTOR GROUP 6730 SOUTH TUCSON BLVD., TUCSON, AZ 85706 USA TITLE ENGINEER FRYE D. ZERKETTS untitled DRAWN BY I. C. SPOTTS DOCUMENT CONTROL NO.1234567 SIZE DATE dd MMM yyyy... - Page 24 REVISION HISTORY ENGINEERING CHANGE NUMBER APPROVED A0(-) A0(+) CNTL GPIO0 A1(-) A1(+) SCLK CLKX DGND A2(-) A2(+) CLKR GPIO1 GPIO1 A3(-) A3(+) GPIO2 GPIO2 AGND DGND AGND MOSI GPIO3 AGND MISO GPIO4 /RESET VCOM AGND REF- TOUT DGND AGND REF+ GPIO5 CONN_EVM_SERIAL CONN_EVM_ANALOG...
-
Page 25: Appendix Ausb-Modevm Schematic
Revision History TP13 +3.3VA ECN Number Approved EXT MIC IN TP14 TP15 +3.3VA MIC BIAS SEL MPWR +3.3VD 49.9K 0.1uF +3.3VD MPWR 1.0K 0.1uF 2.2K 10uF 0.22uF SJ1-3515-SMT 2.7K 2.7K 2.7K C21 - C22 are optional 100K noise filtering caps for microphone and bias lines. -
Page 26: Appendix Busb-Modevm Bill Of Materials
J1, J8, J9 3,5mm Audio Jack, T-R-S, SMD J3, J7 Screw Terminal Block, 2 Position Screw Terminal Block, 3 Position J2, J4–J6 Screw Terminal Block, 4 Position 10 Pin SMT Plug Header SLAU282 – April 2009 TSC2117EVM-K Submit Documentation Feedback... - Page 27 TEST POINT PC MULTI PURPOSE BLK W2–W8 Bus Wire (18-22 Gauge) W14– W18, W20–W22 2 Pin Thru-hole Plug Header (Jumper), 0 .1" spacing W1, W9–W13, W19 3 Position Jumper , 0 .1" spacing TSC2117EVM-K SLAU282 – April 2009 Submit Documentation Feedback...
-
Page 28: Appendix Cusb-Modevm Protocol
Appendix A www.ti.com Appendix A USB-MODEVM Schematic The schematic diagram for USB-MODEVM Interface Board is provided as a reference. SLAU282 – April 2009 USB-MODEVM Schematic Submit Documentation Feedback... - Page 29 REVISION HISTORY ENGINEERING CHANGE NUMBER APPROVED USB Interface Daughtercard Interface USB Interface Daughtercard Interface MCLK MCLK BCLK BCLK LRCLK LRCLK I2SDIN I2SDIN I2SDOUT I2SDOUT MISO MISO MOSI MOSI SCLK SCLK RESET RESET PWR_DWN PWR_DWN P3.3 P3.3 P3.4 P3.4 P3.5 P3.5 P1.0 P1.0 P1.1...
- Page 30 REVISION HISTORY ENGINEERING CHANGE NUMBER APPROVED JMP5 A0(-) A0(+) CNTL GPIO0 A1(-) A1(+) CLKX DGND A2(-) A2(+) CLKR GPIO1 A3(-) A3(+) GPIO2 AGND DGND AGND GPIO3 AGND GPIO4 IOVDD VCOM AGND REF- TOUT DGND +3.3VD AGND REF+ GPIO5 J13A (TOP) = SAM_TSM-105-01-L-DV-P +5VA DAUGHTER-ANALOG J13B (BOTTOM) = SAM_SSW-105-22-F-D-VS-...
- Page 31 REVISION HISTORY ENGINEERING CHANGE NUMBER APPROVED IOVDD C32 +3.3VD +3.3VD 0.1uF 0.1uF 0.1uF +3.3VD IOVDD +3.3VD C34 IOVDD +3.3VD IOVDD +3.3VD +3.3VD SN74LVC1G126DBV VCCA VCCB USB MCK DIR1 0.1uF 0.1uF 0.1uF EXT MCK EXT MCLK DIR2 0.1uF 200k 2.7K 2.7K VCCB VCCA USB I2S...
-
Page 32: Usb-Modevm Bill Of Materials
Lumex SML-LX0603IW-TR Q1, Q2 N-Channel MOSFET Zetex ZXMN6A07F 6MHz Crystal SMD Epson MA-505 6.000M-C0 USB Streaming Controller Texas Instruments TAS1020BPFB 5V LDO Regulator Texas Instruments REG1117-5 3.3V/1.8V Dual Output LDO Regulator Texas Instruments TPS767D318PWP U3, U4 Quad, 3-State Buffers Texas Instruments SN74LVC125APW U5–U7... - Page 33 Appendix B www.ti.com Table B-1. USB-MODEVM Bill of Materials (continued) Designators Description Manufacturer Mfg. Part Number JMP8–JMP14 2-position jumper, 0.1" spacing Samtec TSW-102-07-L-S JMP5, JMP6 3-position jumper, 0.1" spacing Samtec TSW-103-07-L-S JMP7 3-position dual row jumper, 0.1" spacing Samtec TSW-103-07-L-D SMT, half-pitch 2-position switch C&K Division, ITT TDA02H0SK1...
-
Page 34: Usb Control Endpoint Hidsetreport Request
Appendix C www.ti.com Appendix C USB-MODEVM Protocol USB-MODEVM Protocol The USB-MODEVM is defined to be a Vendor-Specific class and is identified on the PC system as an NI-VISA device. Because the TAS1020B has several routines in its ROM which are designed for use with HID-class devices, HID-like structures are used, even though the USB-MODEVM is not an HID-class device. - Page 35 USB-MODEVM Protocol www.ti.com Do the same with a fast mode I C device: 0x12 0xA0 0x02 0x05 0xAA 0x55 Now with an SPI device which uses an 8-bit register address: 0x10 0xA0 0x02 0x05 0xAA 0x55 Now, do a 16-bit register address, as found on parts like the TSC2101. Assume the register address (command word) is 0x10E0: 0x14 0x10 →...
- Page 36 USB-MODEVM Protocol www.ti.com If the command is sent with no problem, the returning byte [0] is the same as the sent one logically ORed with 0x20 - in the preceding first example, the returning packet is: 0x31 0xA0 0x02 0x05 0xAA 0x55 If for some reason the interface fails (for example, the I...
-
Page 37: Gpio Pin Assignments
GPIO Capability www.ti.com The return packet is: 0x21 0xA0 0x02 0x05 0xAA 0x55 assuming that the values written starting at Register 5 were actually written to the device. GPIO Capability The USB-MODEVM has seven GPIO lines. Access them by specifying the interface to be 0x08, and then using the standard format for packets—but addresses are unnecessary. - Page 38 Writing Scripts www.ti.com The first command, i, sets the interface to use for the commands to follow. This command must be followed by one of the following parameters: i2cstd Standard mode I C bus i2cfast Fast mode I C bus spi8 SPI bus with 8-bit register addressing spi16...
- Page 39 Writing Scripts www.ti.com If extensive repeated write commands are sent and commenting is desired for a group of bytes, the > command can be used to extend the bytes to other lines that follow. A usage example for the > command follows: #example script for '>' command i i2cfast...
-
Page 40: Important Notice
IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
