1
Introduction
This user's guide describes the characteristics, operation, and use of the TSC2013 evaluation module
(EVM). This EVM, featuring the TSC2013 resistive dual-touch controller, is a fully-functional USB-powered
platform that allows 4-wire resistive touch-screen panels to be connected to the USB port of a PC or
laptop for evaluation. A complete circuit description, schematic diagram, and bill of materials are included
in this document.
The following related documents are available through the Texas Instruments web site at www.ti.com.
The following lists devices and corresponding device data sheets of devices that are compatible with this
EVM:
TSC2013,
SLVSC89
DRV2605,
SLOS825
REG1117-33,
SBVS001
MSP430F247,
2
EVM Overview
2.1
Features
The TSC2013EVM is a complete evaluation and demonstration kit that includes a USB-based board and
evaluation software for use with a personal computer running Microsoft Windows® operating systems
(OS).
3
Analog Interface
The TSC2013EVM is designed for easy interfacing to 4-wire resistive touch screen panels.
PIN NUMBER
J300.1
J300.2
J300.3
J300.4
SLVUA92 – July 2014
Submit Documentation Feedback
SLAS547I
Table 1. Analog Interface Pinout
SIGNAL
Y–
X–
Y+
X+
Copyright © 2014, Texas Instruments Incorporated
TSC2013EVM User's Guide
DESCRIPTION
Touch screen Y- electrode
Touch screen X- electrode
Touch screen Y+ electrode
Touch screen X+ electrode
User's Guide
SLVUA92 – July 2014
TSC2013EVM User's Guide
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TSC2013EVM and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments TSC2013EVM

  • Page 1 MSP430F247, SLAS547I EVM Overview Features The TSC2013EVM is a complete evaluation and demonstration kit that includes a USB-based board and evaluation software for use with a personal computer running Microsoft Windows® operating systems (OS). Analog Interface The TSC2013EVM is designed for easy interfacing to 4-wire resistive touch screen panels.
  • Page 2 Digital Control The digital control signals are applied through the USB connection and no other connections are required. The TSC2013EVM can also be connected to a DSP or microcontroller interface board through the J202 pin. If external I C control is desired, remove the following resisters: R231, R232, and R233.
  • Page 3: Kit Operation

    TSC2013EVM-PDK Block Diagram Figure 1 shows a block diagram of the TSC2013EVM. The TSC2013 and DRV2605 device are both controlled by an MSP430™ microcontroller (MCU) through an I C interface. One resistive touch panel is connected to the TSC2013 device by a 4-pin FPC connector and an LRA motor is attached as an actuator.
  • Page 4: Quick Start

    FTDI CDM Drivers which is shown in Figure When the driver installation is complete, attach a USB cable from the PC to the TSC2013EVM board. The board receives power from the USB interface and therefore the power-indicator LED (LED502) on the TSC2013EVM should light up when the USB cable is attached.
  • Page 5 Figure 4. Default Software Screen In order to use the touch-screen features, a 4-wire resistive-touch screen must be connected to the J300 pin of the TSC2013EVM, as previously described. Click the Serial Settings button and the window shown in Figure 3 opens.
  • Page 6: Program Description

    Kit Operation www.ti.com Program Description After the TSC2013EVM software is installed, the EVM board can be used to evaluate and develop the TSC2013 device. 7.3.1 1-Finger Trace Panel The touch-screen box in the 1-Finger Trace Panel is updated when a touch is detected on the touch...
  • Page 7 EVM Bill of Materials (BOM) and Schematic www.ti.com EVM Bill of Materials (BOM) and Schematic Table 3 lists the complete BOM for the modular TSC2013EVM. Table 3. TSC2013EVM Bill of Materials DESIGNATORS DESCRIPTION MANUFACTURER PART NUMBER C100, C101, C102, C103, C104, 10-µF, capacitor,10%,SMT0805...
  • Page 8 Vbus SCL_A SCL_A FT232 SDA_A SDA_A UART -> USB MSP430F247 SCL_B SCL_B SDA_B SDA_B PWM_DRV260x DRV_PWM DRV_EN DRV_EN /RST_UART /RST_UART MSP430xx UART2USB Figure 8. TSC2013EVM User's Guide SLVUA92 – July 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 9 3V3_D VOUT C101 C102 C100 10uF 10uF 10uF R101 U101 To TSC2013 REG1117 -3V3 3V3_A Sink 3V3_A VOUT C103 C104 10uF 10uF Figure 10. SLVUA92 – July 2014 TSC2013EVM User's Guide Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 10 To TSC2013 TouchDetected ZoomIn ZoomoOut Left Right Down SCL_A R231 SDA_A R232 /RST R233 J202 From TSC2013 /INT_TSC CON6 V200 V201 V202 V203 Figure 11. TSC2013EVM User's Guide SLVUA92 – July 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 11 R302 SDA_A SCL_A From MSP430Fx R303 SDA_A SCL_A TSC2013 J300 J301 R308 V300 V301 V302 V303 SNSGND R309 /RST C305 100nF R=Ry/4.5 Figure 12. SLVUA92 – July 2014 TSC2013EVM User's Guide Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 12 Case R503 LED500 GREEN Vcc_FT232R CBUS0 /TXD J500 CBUS1 LED501 GREEN CBUS3 /RXD R504 OSCI CBUS2 OSCO CBUS4 R505 /RST C503 10nF Figure 13. TSC2013EVM User's Guide SLVUA92 – July 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 13 ADDITIONAL TERMS AND CONDITIONS, WARNINGS, RESTRICTIONS, AND DISCLAIMERS FOR EVALUATION MODULES Texas Instruments Incorporated (TI) markets, sells, and loans all evaluation boards, kits, and/or modules (EVMs) pursuant to, and user expressly acknowledges, represents, and agrees, and takes sole responsibility and risk with respect to, the following: 1.
  • Page 14 RADIO FREQUENCY REGULATORY COMPLIANCE INFORMATION FOR EVALUATION MODULES Texas Instruments Incorporated (TI) evaluation boards, kits, and/or modules (EVMs) and/or accompanying hardware that is marketed, sold, or loaned to users may or may not be subject to radio frequency regulations in specific countries.
  • Page 15 Les types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2014, Texas Instruments Incorporated spacer Important Notice for Users of EVMs Considered “Radio Frequency Products”...
  • Page 16: Important Notice

    IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest issue.
  • Page 17 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments TSC2013EVM...
