PCM-3664 PC/104 Jumperless 10Base-T
Ethernet Module
Startup Manual

Introduction

The PCM-3664 is a high performance 16-bit jumperless
Ethernet interface module that attaches to the PC/104
connector on your CPU card or PC/104 CPU module. The
module automatically senses whether it is connected to an
8-bit or 16-bit PC/104 system. The PCM-3664 fully complies
with IEEE 802.3 10 Mbps CSMA/CD standards and is 100%
Novell NE2000 compatible.
The modlule includes a built-in 10Base-T transceiver and
RJ-45 connector. An onboard BNC connector supports
10Base-2. Two diagnostic LEDs indicate the operating
status of the module and the network.
The 5 V 10Base-2 transceiver supports IEEE 802.3,
allowing connections of up to 185 m with this coaxial cable.
The PCM-3664 comes with drivers for a wide variety of
networks and operating systems. An optional boot ROM lets
you remotely boot a PC/104 station automatically from a
server, making hard or floppy disks unnecessary.

Packing List

Before you begin installing your card, please make sure that
the following materials have been shipped:
• 1 PCM-3664 PC/104 Ethernet module
• 1 Start-up manual
• CD-ROM or Disks for utility, drivers, and manual (in PDF
format)
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1:
For detailed contents of the PCM-3664, please
refer to the enclosed CD-ROM or disk (in PDF
format).
Note 2:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/
readstep.html
(Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our support
website at:
http://www.advantech.com/support
This manual is for the PCM-3664 series Rev.A1
Part No. 2006366410
Printed in Taiwan

Features

PCM-3664 PC/104 Ethernet module
• Conforms to IEEE 802.3 Ethernet standards, CSMA/
CD protocol for 10 Mbps data transfer
• Hardware and software compatible with Novell
NE2000 adaptor
• Automatically detects 8-bit and 16-bit data bus
• Remote boot ROM socket for diskless operation
• Built-in 10Base-T transceiver for unshielded twisted
pair cabling up to 100 m
• Two diagnostic LEDs indicate network status
• Onboard 32 K memory for high-performance
multipackage buffer
• Software drivers for most popular network
environments
Onboard BNC LAN Connector
• Conforms to IEEE 802.3 10Base-2 standard
• Supports up to 185 m connections on RG-58 thin
coaxial cable

Specifications

Hardware
• PC/104 form-factor: 90 x 96 mm (3.6" x 3.8")
• I/O address: 200, 220, 240, 260, 280, 2A0, 2C0,
300,320, 340, 380 or 3A0
• Interrupt levels: IRQ3, 4, 5, 9, 10, 11, 12 or 15
• Boot ROM address: C0000, C8000, D0000 or
D8000H
• Data bus: 8-bit or 16-bit, auto-sensing
• Connectors: 16-bit PC/104 stackthrough connector
RJ45 connector for 10Base-T, BNC connector for
10Base-2
Software drivers support
• Lantasti 4.x/5.x driver
• NDIS 2.x driver
• Packet driver
• SCO UNIX driver
1st Edition
Dec. 2000
PCM-3664 Startup Manual
1
